Imaging Diffraction Using Maxim at G3/Hasylab - Spatial Resolved Strain Measurements on Linear Friction Welded Dissimilar Materials (AA7020-T6/Ti6AlV

Abstract:

Strain induced by friction welding of dissimilar materials was determined by an imaging diffraction technique using the Material X-ray diffraction Imaging (MAXIM) detector at HASYLAB G3. Applying the sin2Ψ method in ω mode, a stress profile perpendicular to the weld joint was derived. Results are discussed and compared with measurements of the same specimen made at the neutron source of the GKSS Research Centre.
