Real Time Monitoring of the Strain Evolution during Rapid Heat Treatment of Steel Samples by Means of Synchrotron X-Ray Diffraction

Abstract:

An innovative experimental set-up for fast X-ray diffraction analysis on polycrystalline materials has been established at the synchrotron radiation facility ANKA (Karlsruhe, Germany). Key components of the set-up are two fast microstrip line detectors arranged symmetrically around the incident beam in the backscatter region. The capabilities of the set-up are tested by means of in-situ heat treatment experiments on SAE 4140 steel samples. In this feasibility study the heat was introduced by means of either a heating stage or by means of a gas tungsten arc welding torch. It will be shown that the evolution of thermal and elastic lattice strains can be monitored at a sampling rate of up to 4 Hz at a bending-magnet synchrotron beamline. Since the sampling rate may be increased further at a insertion device synchrotron beamline providing higher photon flux, our setup appears to be feasible for monitoring laser treatments in real time.

• Periodical: Materials Science Forum (Volumes 638-642)
• Pages: 2423-2428
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.638-642.2423
• Online since: January 2010
• Authors: Vladimir Kostov, Jens Gibmeier, Stephen Doyle, Alexander Wanner
• Keywords: In Situ Strain Analysis, Real-Time Monitoring, Synchrotron X-Ray Diffraction

References

[1] K. Müller, H.W. Bergmann, Z. Metallkunde, 90 (1999) 881-887.

[2] K. Obergfell, V. Schulze, O. Vohringer, Surface Engineering, 19 (2003) 359-363.

[3] T. Miokovic, V. Schulze, O. Vöhringer, D. Löhe, Härterei-Techn. Mitt., 60 (2005) 142-149.

[4] R. Lin-Peng, T. Ericsson, Scand. J. Metallurgy, 27 (1998) 223-232.

[5] T. Miokovic, Doctorate Thesis, University of Karlsruhe (2005).

[6] B. Schmitt, Ch. Bronnimann, E.F. Eikenberry, et al, Nucl. Instr. Meth. A, 518 (2004) 436-439.

[7] E. Macherauch, P. Müller, Z. angew. Physik, 13 (1961) 305-312.

[8] J. Gibmeier, J. Lu, B. Scholtes, Mat. Sci. Forum, 2002, Vols. 404-407, 659-664.

[9] V. Hauk, Structural and Residual Stress Analysis by Nondestructive Methods, Elsevier (1997).
