Estimation of Magnetization Distribution in Permanent Magnet of Brushless DC Motor

Abstract:

This paper proposes a method to estimate the magnetization distribution in permanent magnet of a Brushless DC motor when the excitation voltage of a magnetizer is changed. First, we show from the experimental results that there is an optimal excitation voltage to reduce the cogging torque of the motor. Next, we show that it is possible to estimate the magnetization distribution in the permanent magnet by using the measured flux density distribution and cogging torque.

• Periodical: Materials Science Forum (Volume 670)
• Pages: 360-368
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.670.360
• Online since: December 2010
• Authors: Takeo Ishikawa, Kouki Yonetake, Nobuyuki Kurita, Masahisa Tsuchiya
• Keywords: Blushless DC Motor, Magnetization State, Permanent Magnet

References

[1] Jin Hur, D. S. Hyun and J. P. Hong, A Method for Reduction of Cogging Torque in Brushless DC Motor Considering the Distribution of Magnetization by 3DEMCN, IEEE Trans. on Magnetics, vol. 34, no. 5, pp.3532-3535, (1998).

DOI: 10.1109/20.717833

[2] S. C. Park, T. H. Yoon, B. I. Kwon, H. S. Yoon and S. H. Won, Influence on Brushless DC Motor Performance Due to Unsymmetric Magnetization Distribution in Permanent Magnet, IEEE Trans. on Magnetics, vol. 36 no. 4, pp.1898-1901, (2000).

DOI: 10.1109/20.877817

[3] C. S. Koh, B. K. Kang, J. S. Ryu, and J. S. Seol The Effects of the Distribution of Residual Magnetization on the Cogging Torque and Switching Signals in Permanent Magnet Motors, IEEE Trans. on Magnetics, vol. 38, no. 2, pp.1217-1220, (2002).

DOI: 10.1109/20.996311

[4] K. Yonetake, T. Ishikawa, M. Matsunami, M. Tsuchiya The Cogging Torque Characteristics of a Spindle Motor by the Magnetization State in the Permanent Magnet, The Paper of Technical Meeting on Rotating Machinery, IEE Japan, RM-07-59, 2007. (in Japanese).
