PRECIX, Robotic System for Residual Stress Analysis by X-Ray Diffraction

Abstract:

In the last years, a new residual stress analysis system by X-ray diffractions has been developed by CETIM and INEL companies. This system called PRECIX is based on an industrial 6 axis robot. The technological performance is, like a 4 circle goniometer, to set together at the end of the sixth axes an x-ray source with a conventional size X-ray source, energy and position sensitive linear detector and an embedded long distance positioning system. PRECIX is an all-in-one system including all electrical and electronic items to perform residual stress analysis. This paper presents PRECIX in detail with a contactless positioning system, a new software getting a fully transparent utilisation for the users. Internal round-robin analysis with external reference samples and different geometries parts performed are presented to compare PRECIX results and other already validated X-ray diffraction systems.

• Periodical: Materials Science Forum (Volume 681)
• Pages: 202-208
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.681.202
• Online since: March 2011
• Authors: Fabien Lefebvre, J.M. Le Roux, C. Charles, H. Pillière, E. Berthier, C. Fontugne
• Keywords: Residual Stress, System, X-Ray Diffraction (XRD)
