Integration of Residual Stresses in the Design of Mechanical Parts

Abstract:

This paper presents an original approach in mechanical design to integrate the manufacturing constraints in the final CAD model. A specific user-interface is proposed to integrate manufacturing constraints (for example tolerances) and manufacturing consequences (for example roughness or hardening) into the model. One of the important consequences of manufacturing processes is the generation of residual stresses into the part. An appropriate tool has been developed and used as a design tool to manage the global evolution of residual stresses in the mechanical part and to obtain the deformed geometry resulting from the applied manufacturing plan. These results could eventually be used in fatigue simulation. To support the model, a database is used for the integration of residual stresses from stored experimental results, analytical or numerical calculations. An example of a metal sheet, laminated and deformed by shot peening is given, the deformed geometry is rebuilt and compared to the experimental results.

• Periodical: Materials Science Forum (Volume 681)
• Pages: 255-260
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.681.255
• Online since: March 2011
• Authors: Jawhar Elgueder, Lionel Roucoules, Emmanuelle Rouhaud, Florent Cochennec
• Keywords: Design for Manufacturing, Fatigue Design, Manufacturing Constraint

References

[1] Lu J. Prestress Engineering of Structural Material: A Global Design Approach to the Residual Stress Problem, Handbook of Residual Stress Formation and Distorsion of Steel, ASM, 2002, pp.11-26.

[2] Skander A. Méthode et modèle DFM pour le choix des procédés et l'intégration des contraintes de fabrication vers l'émergence de la solution produit. Ph-D thesis, UTT, Troyes, (2006).

[3] Roucoules L., Skander A. Manufacturing process selection and integration in product design. Analysis and synthesis approaches. Proceedings of the CIRP Design seminar, Grenoble, (2003).

[4] Roucoules L., Lafon P. et al. Knowledge intensive approach towards multiple product modelling and geometry emergence to foster cooperative design. Proceedings of the CIRP Design seminar, Kananaskis, (2006).

[5] Lu J., Flavenot J.F., Lieurade H.P. Intégration des notions de contraintes résiduelles dans les bureaux d'études, démarche globale. In Les contraintes résiduelles au bureau d'études. Senlis : CETIM, 1991. ISBN 2-85400-216-0.

DOI: 10.1051/metal/199794020187

[6] O'Hara P. Peen-forming - A developing technique. Proceedings of the ICSP8, Garmisch-Partenkirchen (2002).

[7] Guagliano M. Relating Almen intensity to residual stresses induced by shot-peening: a numerical approach. In Journal of Materials Processing Technology. 110: 267-286, (2001).

DOI: 10.1016/s0924-0136(00)00893-1

[8] Grasty L. V., Andrew C. Shot peen forming sheet metal: finite element prediction of deformed shape. In Journal of Engineering Manufacture. 210: 361-365, (1996).

DOI: 10.1243/pime_proc_1996_210_129_02

[9] Homer S. E., VanLuchene R. D. Aircaft wing skin contouring by shot-peening. In Journal of Material. Shaping Technologies. 0 (0): 2-8, (1991).

[10] Han K., Owen D. R. J. et al. Combined finite/discrete element and explicit/implicit simulations of peen forming process. In engineering computations, 19(1): 92-118, (2002).

DOI: 10.1108/02644400210413667

[11] COCHENNEC F. Simulation numérique du grenaillage de mise en forme pour une intégration produit-procédés en conception mécanique ». Ph-D thesis, UTT, Troyes, (2009).

[12] Skander A, Roucoules L., Klein Meyer JS, 2008, Design and manufacturing interface modelling for manufacturing processes selection and knowledge synthesis in design. In International Journal of Advanced Manufacturing Technology, DOI 10. 1007/s00170-007-1003-2, n°37, (2008).

DOI: 10.1007/s00170-007-1003-2

[13] Boothroyd G., Dewhurst P. et al. Product design for manufacture and assembly. Marcel Dekker, 1994, ISBN 0- 82479-176-2.

[14] Roucoules L. Méthodes et connaissances : contribution au développement d'un environnement de conception intégrée. Ph-D thesis, INPG, Grenoble, (1999).

[15] E. Rouhaud, D. Deslaef et al. In Handbook on Residual Stress, Society for Experimental Mechanics, USA, (2005).
