Microstructure and Wear-Resistant SiC Film by RF Magnetron Sputtering

Abstract:

A wear-resistant SiC (silicon carbon) film on titanium substrate was prepared by magnetron sputtering technology. The film exhibits low nano-hardness of 12.1 GPa and low Young's modulus of 166.2 GPa together with superior friction/wear properties. As sliding against Si₃N₄ (silicon nitride) ball (2 mm in radius) at room temperature under Kokubo simulation body fluid condition, the film exhibited the friction coefficient of about 0.215 and the special wear rate in the order of magnitude of 10⁻⁵ mm³/ Nm even at the load of 500g without film cracking and interface delaminating. The high film-cracking and interface-delaminating resistance is due to the low hardness of the film and the good film/substrate modulus match caused by the low elastic modulus of the film.

You might also be interested in these eBooks

Functional and Electronic Materials, IUMRS-ICA2010

View Preview

Info:

Periodical:

Materials Science Forum (Volume 687)

Pages:

580-584

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.687.580

Citation:

Cite this paper

Online since:

June 2011

Authors:

K. Tian, Xiao Jing Xu, Zhen Fan, Xin Ni Hao, Dan Chen, Xi Ling Xin, Xin Lan Sheng

Keywords:

Friction and Wear, Load-Bearing Capacity, SiC Film, Simulation Body Fluid

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] P. Aspenberg, A. Anttila, Y.T. Konttinen, R. Lappalainen, S.B. Goodman, L. Nordsletten and S. Santavirtall: Biomaterials Vol. 17(8) (1996), p.807.

DOI: 10.1016/0142-9612(96)81418-9

Google Scholar

[2] J. Esteve, A. Lousa, E. Martinez, H. Huck, E.B. Halac, M. Reinoso: Diamond Relat. Mater. Vol. 10(3-7) (2001), p.1053.

Google Scholar

[3] T. Kokubo, H. Kushitani, S. Sakka, T. Kitsugi, T. Yamamuro: J. Biomed. Mater. Res. Vol. 24(6) (1990), p.721.

DOI: 10.1002/jbm.820240607

Google Scholar

[4] N. Fujisawa, R.M. David, L.J. Natalie, C.W. John, V. S. Michael: Wear Vol. 260(1-2) (2006), p.62.

Google Scholar

[5] A. Leyland, A. Matthews: Wear Vol. 246(1-2) (2000), p.1.

Google Scholar

[6] K.H. Lee, O. Takai: Diamond Relat. Mater. Vol. 14(9) (2005), p.1444.

Google Scholar

[7] W. Österle, D. Klaffke, M. Griepentrog, U. Gross, I. Kranz, C.W. Knabe: Wear Vol. 264(7-8) (2008), p.505.

DOI: 10.1016/j.wear.2007.04.001

Google Scholar
