Microstructural Studies of NiCoMnIn Magnetic Shape Memory Ribbons

Abstract:

In present paper two ribbons of the Ni₄₄Co₆Mn₃₆In₁₄ (at.%) were prepared under different melt-spinning technique conditions. Microstructure of the ribbons was studied by scanning electron microscopy (SEM). Depending on the liquid ejection overpressure two types of ribbons microstructures were observed. Ribbon T1 for which ejection overpressure was 1.5 bar showed typical melt-spun ribbon microstructure consisting of a top layer of small equi-axial grains and columnar grains below. For T2 ribbon (ejection overpressure 0.2 bar) only a small fraction of the columnar grains were observed. Structure analysis of the ribbons performed by XRD showed that at room temperature both ribbons have B2 parent phase superstructure. No gamma phase precipitates were observed. In order to determine the orientation of the grains the EBSD technique was applied.

• Periodical: Materials Science Forum (Volumes 738-739)
• Pages: 436-440
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.738-739.436
• Online since: January 2013
• Authors: Krystian Prusik, Katarzyna Bałdys, Danuta Stróż, Tomasz Goryczka, Józef Lelątko
• Keywords: EBSD, Ferromagnetic Shape Memory Alloys (FSMAs), Ni-Mn-Co-in, Ribbon, TEM

References

[1] Y. Sutou, Y. Imano, N. Koeda, T. Omori, R. Kainuma, K. Ishida, K. Oikawa, Appl. Phys. Lett. 85 (2004) 4358.

DOI: 10.1063/1.1808879

[2] K. Koyama, H. Okada, K. Watanabe, T. Kanomata, R. Kainuma, W. Ito, K. Oikawa, K. Ishida, Appl. Phys. Lett. 89 (2006) 182510.

DOI: 10.1063/1.2374868

[3] V.K. Sharma, M.K. Chattopadhyay, K.H.B. Shaeb, A. Chouhan, S.B. Roy, Appl. Phys. Lett. 89 (2006) 222509.

DOI: 10.1063/1.2399365

[4] R. Kainuma, Y. Imano, W. Ito, Y. Sutou, H. Morito, S. Okamoto, O. Kitakami, K. Oikawa, A. Fujita, T. Kanomata, K. Ishida, Nature 439 (2006) 957.

DOI: 10.1038/nature04493

[5] K. Oikawa, Y. Imano, V.A. Chernenko, F. Luo, T. Omori, Y. Sutou, R. Kainuma, T. Kanomata, K. Ishida: Mat. Trans., Vol. 46, No. 3 (2005), pp.734-737.

DOI: 10.2320/matertrans.46.734

[6] A. Sozinov, A.A. Likhachev, N. Lanska, K. Ullakko, Appl. Phys. Lett., Vol. 80 (2002) 1746-1748.

DOI: 10.1063/1.1458075

[7] A.A. Likchachev, K. Ullakko: Phys. Lett. A Vol. 275 (2000) 142.

[8] M. Pötschke, U. Gaitzsch, S. Roth, B. Rellinghause, L. Schultz, J. Magn. Magn. Mater. 316 (2007) 383.

[9] Z.H. Liu, X.X. Zhang, M. Zhang, X.F. Dai, H.N. Hu, J.L. Chen, G.H. Wu: Phys. Lett. A 329 (2004) 214.

[10] A. Böhm, S. Roth, G. Naumann, W.G. Drossel, R. Neugebauer: Mater. Sci. Eng. A 481-482 (2008) 266.

[11] S. Besseghini, E. Villa, F. Passaretti, M. Pini, F. Bonfanti: Mat. Sci. Eng. A 378 (2004) 415.

[12] L. Bin, W. Hua-Bin, L. Yan, L. Ji-Xuan, W.H. Lei: Trans. Nonferrous Met. Soc. China 16 (2006) 843.

[13] H. Morawiec, T. Goryczka, A. Drdzeń, J. Lelątko, K. Prusik, Solid State Phenomena, 154 (2009) 133.

DOI: 10.4028/www.scientific.net/ssp.154.133

[14] O. Gutfleisch, A. Yan, K. -H. Müller, J. Appl. Phys., 97 (2005) 10M305.
