Mapping of Phase Distribution in Electron Holography with a Stage-Scanning System

Abstract:

A new method is proposed for mapping of phase distribution in electron holography. A stage-scanning system was used for moving the specimen to obtain a series of holograms with different specimen positions in a fixed electron-optics configuration. By applying a digital aperture which selects an area on holograms with different specimen positions, an interferogram of the specimen can be obtained directly without a complex reconstruction method such as the one using Fourier transformation. Experimental results for a Co particle demonstrated the practicability of this method.
