Numerical Analysis of the Effect of Phase Transformation on Residual Stresses in an Autogenous Beam Edge Weld

Abstract:

This paper presents the numerical analysis of phase proportions and residual stresses in an autogenous beam edge weld. The thin beam was welded running a heat source along its longer edge using a TIG process. There is no addition of any material so the focus of modelling the process could be concentrated on the thermal analysis and the phase transformations. Temperature dependent material properties and a continuous cooling transformation (CCT) diagram of the base material were provided. The simulations took into account metallurgical effects and used a Goldak-type heat source. Simulations with and without phase transformations were carried out, in order to analyse the effect on the predicted residual stress.

• Periodical: Materials Science Forum (Volumes 768-769)
• Pages: 652-659
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.768-769.652
• Online since: September 2013
• Authors: Martina M. Joosten
• Keywords: Ferritic Steel, Modeling, Phase Transformation, Residual Stress

References

[1] J. B. Leblond, J. Devaux, A new kinetic model for anisothermal metallurgical transformations in steels including effect of austenite grain size, Acta Metallurgica. Vol. 32, No. 1 (1984) 137-146.

DOI: 10.1016/0001-6160(84)90211-6

[2] SYSWELD 2011, Reference Manual, ESI.

[3] NeT TG5 Numerical Analysis Protocol, technical paper, European Network on Neutron Techniques Standardisation for Structural Integrity (2009).

[4] S. Bate, N. Shallcross, K. Stone, J. Francis, A. Mark, C. Gill, Development of material model parameters suitable for the finite element simulation of ferritic welds, Proceedings of the ASME 2012 PVP Conference, Toronto, Canada, PVP2012-78299.

DOI: 10.1115/pvp2012-78299

[5] C.J. Hamelin, O. Muránsky, V. Luzin, P. Bendeich, L. Edwards, Accounting for phase transformations during welding of ferritic steels, Proceedings of the ASME 2011 PVP Conference, Baltimore, USA, PVP2011-57426.

DOI: 10.1115/pvp2011-57426

[6] C. J. Hamelin, O. Muránsky, V. Luzin, P. Bendeich, L. Edwards, Predicting post-weld residual stresses in ferritic stress weldments, Proceedings of the ASME 2012 PVP Conference, Toronto, Canada, PVP2012-78073.

DOI: 10.1115/pvp2012-78073

[7] A.P. Warren, I. Symington, S. K. Bate, J. A. Francis, M. Turski, P. R. Hurrell, The prediction of residual stresses in an autogenously welded ferritic beams, Proceedings of the ASME 2008 PVP Conference, Chicago, USA, PVP2008-61509.

DOI: 10.1115/pvp2008-61509
