Three-Dimensional Magnetic Field Analysis for Local Induction Heating of Steel Sheet by Using Magnetic Flux Concentration Plate

Abstract:

In general, the magnetic properties of electrical steel sheets are strongly influenced by mechanical stress. We have reported the measurement results of vector magnetic properties of a non-oriented electrical steel sheet under stress conditions. From these results, it is possible to control the vector magnetic property by applying local mechanical stress. Therefore, we next focus on an induction heating technique that applies mechanical stress in a non-oriented electrical steel sheet. It is very important to control the eddy current distribution inside the non-oriented electrical steel sheet. This paper presents a magnetic flux concentration plate structure to control the eddy current in steel sheets by using an induction heating technique. The magnetic flux concentration plate structure is investigated in a three-dimensional magnetic field analysis by the finite element method.

• Periodical: Materials Science Forum (Volume 792)
• Pages: 87-92
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.792.87
• Online since: August 2014
• Authors: Yuichiro Kai*, Yuji Tsuchida, Takashi Todaka, Masato Enokizono
• Keywords: Eddy Current, Induction Healing, Magnetic Flux Concentration Plate, Steel Sheet

References

[1] Yousuke Kurosaki, Hisashi Mogi, Hiroyasu Fujii, Takeshi Kubota, Morio Shiozaki, Importance of punching and workability in non-oriented electrical steel sheets, Journal of Magnetisma and Magnetic Materials, pp.2474-2480, (2008).

DOI: 10.1016/j.jmmm.2008.04.073

[2] A. Schoppa, J. Schneider, C. -D. Wuppermann, Influence of the manufacturing process on the magnetic properties of non-oriented electrical steel, Journal of Magnetism and Magnetic Materials, pp.215-216, (2000).

DOI: 10.1016/s0304-8853(00)00070-6

[3] Yuichiro Kai, Yuji Tsuchida, Takashi Todaka, Masato Enokizono, Influence of Stress on Vector Magnetic Property Under Rotating Magnetic Flux Conditions, IEEE Transactions on Magnetics, Vol. 48, No. 4, pp.1421-1424, (2012).

DOI: 10.1109/tmag.2011.2173756

[4] Yuichiro Kai, Yuji Tsuchida, Takashi Todaka, Masato Enokizono, Influence of Stress on Vector Magnetic Property Under Alternating Magnetic Flux Conditions, IEEE Transactions on Magnetics, Vol. 47, No. 10, pp.4344-4347, (2011).

DOI: 10.1109/tmag.2011.2158397

[5] Yoshimoto Takeshi, Yamada Sotoshi, Bessho Kazuo, A Finite Element Calculation Method of 3-D Eddy Current Diffusion Problem and Its Application to a Flux Concentration Apparatus, T. IEE Japan, Vol. 107-D, No. 6, pp.796-803, (1987).

DOI: 10.1541/ieejias.107.796
