Quantitative Defect Detection inside Metal Casting Specimens by Means of MFES

Abstract:

An NDE measurement for internal defects of metal casting products is presented. The internal defects are often made in the manufacturing process of metal casting. From the view point of non-destructive evaluation (NDE), it is very difficult to make artificial defects that simulate actual internal defects. Therefore, we prepared a lot of metal casting samples that may include defects, and investigated the relation between the defect dimensions and the spectrogram that were generated by Multi-Frequency Excitation and Spectrogram Method (MFES).

• Periodical: Materials Science Forum (Volume 792)
• Pages: 104-109
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.792.104
• Online since: August 2014
• Authors: Shoichiro Nagata, Takemi Sakamoto, Masato Enokizono
• Keywords: Eddy Current Testing, Metal Casting, Non-Destructive Evaluation

References

[1] S. Nagata, H. Kai and M. Enokizono, Non-destructive Evaluation for Internal Defect of Metal Casting, Materials Science Forum Vol. 670, pp.151-157, (2011).

DOI: 10.4028/www.scientific.net/msf.670.151

[2] S. Nagata, H. Kai, and M. Enokizono, Eddy Current Testing for Internal Defect inside Metal Casting, Journal of the JSAEM, Vol. 19, No. 2, p.115 – 120, June, (2012).

[3] T. Chady, M. Enokizono, and R. Sikora, Crack Detection and Recognition Using Eddy Current Differntial Probe, IEEE Transactions on Magnetics, Vol 35, No. 3, pp.1849-1852, May (1999).

DOI: 10.1109/20.767393

[4] S. Nagata, M. Enokizono, T. Chady and R. Sikora, Low Frequency Excitation of MFES, Electromagnetic Nondestructive Evaluation (VIII), IOS Press, pp.183-189, (2004).

[5] S. Nagata, M. Enokizono, Variable Single-Frequency Excitation and Spectrogram Method, Electromagnetic Nondestructive Evaluation (VIII), IOS Press, pp.183-189, (2004).
