Surface Quality Improvement and Tool Footprint Analysis in a Robotic Grinding Cell

Abstract:

Finishing process (Grinding and Polishing), is still manually performed, specially in free form surface parts. This involves a series of remaining problems, mainly related with the geometrical shape of the finished part. In traditional manually finishing task, the final quality aspect of the part is the only parameter to be controlled. This supposes a lack in the quality parameter control, mainly in high level parts, as in automotive, aeronautics or mould making parts. Manual finishing has not any control about the amount of material removed, during finishing process, affecting this way to the final geometrical shape of the product. This is the reason why this investigation proposes an exhaustive research of the parameter influencing the finishing tasks, and defining a finishing methodology adapted for an automatic process executed by a spherical robot. Making it an automatic way, and controlling paths, tool, abrasive, and defining a mathematical model for the finishing process, final quality of the part and product will be optimized, from a quality point of view, at the same time process time and cost is reduced.

• Periodical: Materials Science Forum (Volume 797)
• Pages: 163-168
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.797.163
• Online since: June 2014
• Authors: José Antonio Dieste*, Angel Fernández, David Roba
• Keywords: Abrasive, Finishing, Foot Print, Grinding, Polishing, Robot Polishing

References

[1] J.J. Márquez, J.M. Pérez, J. Ríos, A. Vizán, Process modelling for robotic polishing. Journal of Materials Processing Technology. 159 (2005) 69-82.

DOI: 10.1016/j.jmatprotec.2004.01.045

[2] Y. Li, S.M. Gracewski, P.D. Funkebusch, J. Ruckman, Analysis of chatter in contour grinding of optical materials. International Journal of Machine Tools & Manufacture, 42 (2002) 1095-1103.

DOI: 10.1016/s0890-6955(02)00062-7

[3] J.M. Zhan, Z. Cao, J. Zhao, Path Planning gor Robot in Free-Form Surfaces Polishing, Key Engineering Materials 304-305 (2006) 426-430.

DOI: 10.4028/www.scientific.net/kem.304-305.426

[4] F. Nagata, Y. Kusumoto, Y, Fujimoto, K. Watanabe, Robotic sanding system for new designed furniture with free-formed surface. Robotics and Computer-Integrated Manufacturing, 23 (2007) 271-279.

DOI: 10.1016/j.rcim.2006.04.004

[5] J.A. Dieste, A. Fernández, D. Roba, Finishing of Free Form Surfaces Using Milling Machine and Spherical Robot, Advanced Science Letters 19 (2013) 849-882.

DOI: 10.1166/asl.2013.4855
