Studying on High Temperature Thermoplastic of High Carbon Steel

Abstract:

High temperature thermoplastic of 50Mn2V casting slab was tested by Gleeble-1500 thermal simulator machine. The morphology, microstructure and composition of fracture surfacewere observed and analyzed by optical microscope (OM), scanning electron microscope (SEM) and energy dispersive spectrometer (EDS).The results show that, there are two brittle temperature zones of 50Mn2V casting slab at the temperature of 600~950°C and 1300~1465°C, respectively, The section shrinkaging rate is less than 60%. The fracture mode changes from mixed one dominated by intergranular to toughness transgranular one with the increase of temperature at the range of 600~1250°C. However, the fracture is along with the solid-liquid phase at the range of 1300°C~ melting point.

• Periodical: Materials Science Forum (Volumes 809-810)
• Pages: 384-389
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.809-810.384
• Online since: December 2014
• Authors: Lang He*, Yu Tang
• Keywords: 50Mn2V, Brittle Temperature Zone, Fracture Mode, High Temperature Thermoplastic

References

[1] Z. B Dong, H. X Dong, Study on the Adaptability of Process of 50Mn2V Steel, [J] Wuhan Steel Technology, 2008. 46（2）: 16-18.

[2] J Wang, Study on the Optimization of Continuous Casting Process and Improving the Quality of Thin Slab Casting Billet, [D]Shenyang, Northeastern University Institute of Metallurgy, 2006：1-4.

[3] Y Wang, The Modern Continuous Casting Using Manual[M] Metallurgical Industry Press, 2010: 100-125.

[4] Y. K Yang, T. L Wu, Xianmei Jiang, High Temperature Strength of Metal and Test[M] Shanghai Science and Technology Press, 1984: 33-37.

[5] J. S Cheng, J Liu, Analysis of the Behavior of HG70 High Temperature Thermal Plastic Steel Concasting Billet[J] Iron and Steel Research, 2010, 38（3）：27-29.

[6] Y. H Pan, Research on the Two Cooling Technology in High Carbon Steel Billet Continuous Casting[D] Chongqing, Chongqing University Institute of Metallurgy, 2008: 15-20.

[7] Y. Y Hu, Y. Y Ma, Stainless Steel Continuous Casting Temperature Control and Optimization of Two Cooling Process[C], The China Metals Society of Continuous Casting Two Cooling Technology Exchange Meeting. 2005: 170-178.

[8] Lankford W T. Some Considerations of Strength and Ductility in the Continuous Casting Process[J]. Metallurgical Transactions. 1982. 3(4): 1331-1357.

DOI: 10.1007/bf02643017

[9] Y. J Hu, J. T Han, Study on SCM435 High Temperature Hot Steel Billet Plastic[J], Journal of Steelmaking, 2010, 26（4）：50-54.
