Microstructure and Properties of Friction Stir Welded Mg-1Al-xSn-0.3Mn Magnesium Alloys

Abstract:

For the study of the weldability of new-typed Mg-1Al-xSn-0.3Mn (x=1,3) magnesium alloys, the plates of extruded Mg-1Al-xSn-0.3Mn (x=1,3) magnesium alloys with a thickness of 2.8 mm were friction stir welded by butt. And the microstructure and properties were tested and analyzed by X-ray non-destructive test, OM, SEM, EDS, microhardness and tensile test. The results show that the above-mentioned magnesium alloys could be successfully butt-welded without any defect by friction stir welding, the microstructure in the NZ was fine and equiaxed, and some grains in the TMAZ were elongated in the form of bars. Moreover, the tensile strength of the friction stir weld could reached over 85% that of the base material and the HAZ at advancing side of the weld had the lowest hardness.

• Periodical: Materials Science Forum (Volume 816)
• Pages: 349-355
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.816.349
• Online since: April 2015
• Authors: An Lian Xu, Fu Sheng Pan, Xian Quan Jiang, Cheng Li, Yang Ran
• Keywords: Friction Stir Welding, Magnesium Alloy, Mechanical Property, Mg-Al-Sn-Mn Alloy, Microstructure

References

[1] Pavel Lukáč and Zuzanka Trojanová, Hardening and softening in magnesium alloys, in: Frank Czerwinski (Eds. ), magnesium alloys design, processing and properties, Intech, Croatia, 2011, pp.1-2.

DOI: 10.5772/13986

[2] C.Y. Wu, J. Zhang, State-of-art on corrosion and protection of magnesium alloys based on patent literatures, Trans. Nonferrous Met. Soc. China. 21(2011) 892-902.

DOI: 10.1016/s1003-6326(11)60799-1

[3] L. Zhou, K. Nakata, J. Liao, T. Tsumura, Microstructural characteristics and mechanical properties of non-combustive Mg–9Al–Zn–Ca magnesium alloy friction stir welded joints, Mater Design. 42(2012) 505-512.

DOI: 10.1016/j.matdes.2012.06.005

[4] J. Yang, D. Wang, B.L. Xiao, D.R. Ni, Z.Y. Ma, Effects of rotation rates on microstructure, mechanical properties, and fracture behavior of friction stir-welded (FSW) AZ31 magnesium alloy, Metall Mater Trans A. 44A(2013) 517-530.

DOI: 10.1007/s11661-012-1373-4

[5] J. Yang, B.L. Xiao, D. Wang, et al. Effects of heat input on tensile properties and fracture behavior of friction stir welded Mg-3Al-1Zn alloy, Mat Sci Eng A-Struct. 527(2010) 708-714.

DOI: 10.1016/j.msea.2009.09.044

[6] L. Commina, M. Dumont, R. Rotinata, F. Pierrona, J. Massec, L. Barrallier, Influence of the microstructural changes and induced residual stresses on tensile properties of wrought magnesium alloy friction stir welds, Mat Sci Eng A-Struct. 551(2012).

DOI: 10.1016/j.msea.2012.05.021

[7] S.H. Park, Y.S. Sato, H. Kokawa, Effect of micro-texture on fracture location in friction stir weld of Mg alloy AZ61 during tensile test, Scripta Mater. 49 (2003) 161-166.

DOI: 10.1016/s1359-6462(03)00210-0

[8] C.I. Chang, C.J. Lee, J.C. Huang. Relationship between grain size and Zener-Holloman parameter during friction stir processing in AZ31 Mg alloys, Scripta Mater. 51(2004) 509-514.

DOI: 10.1016/j.scriptamat.2004.05.043

[9] M. Pareek, A. Polar, F. Rumiche, Proceedings of the Seventh International Conference on Trends in Welding Research, Pine Mountain, GA, United States, May 16–20, 2005, ASM International, 2006, p.421–426.

[10] S.H. Park, Y.S. Sato, H. Kokawa. Basal plane texture and flow pattern in friction stir weld of a magnesium alloy, Metall Mater Trans A. 34 (2003) 987–994.

DOI: 10.1007/s11661-003-0228-4

[11] M.A. Gharacheh, A.H. Kokabi, G.H. Daneshi, B. Shalchi, R. Sarrafi, The influence of the ratio of rotational speed/traverse speed, (ε/v) on mechanical properties of AZ31 friction stir welds, Int J Mach Tool Manu. 46(2006) 1983-(1987).

DOI: 10.1016/j.ijmachtools.2006.01.007

[12] S. Lim, S. Kim, C. Lee, C.D. Yim, S.J. Kim, Tensile behavior of friction-stir-welded AZ31-H24 mg alloy, Metall Mater Trans A. 36(2005) 1609-1612.

DOI: 10.1007/s11661-005-0252-7
