Robust Design of UOE Forming Process Based on Support Vector Machine

Abstract:

Fluctuations in material properties of the incoming steel for UOE forming process are widespread. According to the statistics, the fluctuation range of the yield strength of the same grade pipeline steel is around 80MPa. Robust optimization methods have been widely applied in sheet metal forming area. In this paper, experiments were conducted to investigate how a stochastic material behavior of noise factors affected UOE forming quality. Robust design models integrated with response surface method for UOE forming process were established to minimize impact of the variations and improve the qualified rate of UOE pipe ovality. Support vector machine in both classification and regression was adopted to map the relation between input process parameters and forming qualities. The deterministic and robust optimization results are presented and compared, demonstrating increased process robustness and decreased number of product rejects by application of the robust optimization approach.

• Periodical: Materials Science Forum (Volume 817)
• Pages: 523-530
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.817.523
• Online since: April 2015
• Authors: Tian Xia Zou, Guang Han Wu, Da Yong Li, Qiang Ren, Ying Hong Peng
• Keywords: Material Fluctuation, Ovality, Robust Design, Support Vector Machine, UOE Forming

References

[1] J. Raffo, R. G. Toscano, L. Mantovano, Numerical model of UOE steel pipes: forming process and structural behaviors, Mecanica Computacional 26 (2007) 317-333.

[2] C.E. Murphey, C.G. Langner, Ultimate pipe strength under bending, collapse and fatigue. In: Proceedings of the fourth International Conference on Offshore Mechanics and Arctic Engineering 1(1985) 467-77.

[3] M.K. Yeh, S. Kyriakides, On the collapse of inelastic thick-walled tubes under external pressure. ASME Journal of Energy Resources Technology 108(1986) 35-47.

DOI: 10.1115/1.3231239

[4] M.K. Yeh, S. Kyriakides, Collapse of deepwater pipelines. ASME Journal of Energy Resources Technology 110 (1988) 1-11.

DOI: 10.1115/1.3231355

[5] V.A. Vladimir, V.K. Viacheslav, E.S. Vadim, A simulation technology for a full cycle of steel line pipe manufacturing operations, Advances in Mechanical Engineering 2011 (2011) 1-7.

[6] M.D. Herynk, S. Kyriakides, A. Onoufriou, H.D. Yun, Effects of the UOE/UOC pipe manufacturing processes on pipe collapse pressure, International Journal of Mechanical Sciences 49(5) (2007) 533-553.

DOI: 10.1016/j.ijmecsci.2006.10.001

[7] G. Ambrogio, F. Gagliardi, L. Filice, Robust design of incremental sheet forming by Taguchi's method, 8th CIRP Conference on Intelligent Computation in Manufacturing Engineering 12 (2013) 270-275.

DOI: 10.1016/j.procir.2013.09.047

[8] J.H. Wiebenga, E.H. Atzema, Y.G. An, H. Vegter, A.H. van den Boogaard, Effect of material scatter on the plastic behavior and stretchability in sheet metal forming, Journal of Materials Processing Technology 214 (2014) 238-252.

DOI: 10.1016/j.jmatprotec.2013.08.008

[9] T. Jansson, L. Nilsson, Optimizing sheet metal forming processes-using a design hierarchy and response surface methodology, Journal of Materials Processing Technology 178 (2006) 218-233.

DOI: 10.1016/j.jmatprotec.2005.03.040

[10] Y. Tang J. Chen, Robust design of sheet metal forming process based on adaptive importance sampling, Struct Multidisc Optim 39 (2009) 531-544.

DOI: 10.1007/s00158-008-0343-3

[11] T. Zou, Q. Ren, Y. Peng, D. Li, D. Tang, J. Han, X. Li, X. Wang, Numerical simulation of X90 UOE pipe forming process, NUMISHEET 2014: The 9th International Conference and Workshop on Numerical Simulation of 3D Sheet Metal Forming Processes 1567 (2013).

DOI: 10.1063/1.4850116

[12] V. Vapnik, The nature of statistical learning theory, Springer, Berlin (1995).
