Highly-Sensitive Humidity Sensors for Condition Monitoring of Hybrid Laminates

Abstract:

In recent years fibre-reinforced polymers (FRPs) gained importance in a wider field of application due to such favourable properties as low mass and tailorable mechanical strength. However, water penetrating into the lightweight material can lead to a loss of shear strength and finally to a collapse of the whole mechanical structure. Consequently, the integration of humidity sensors into compound materials is able to promote the reliability via online condition monitoring. An innovative concept is the use of ceramics-polymer-composites, which are well suited for the integration into lightweight structures during inline production. Composite and polyimide based humidity sensors have been manufactured by flexographic printing and spin-coating processes. A 5-fold increase in sensor’s capacity related to a humidity change from 10 to 80 % r.h. manifests the outstanding sensitivity of manufactured composite sensors. In addition, FRP-integrated polyimide sensors showed a significant response to water penetration, whereby the capability of condition monitoring could be confirmed.

• Periodical: Materials Science Forum (Volumes 825-826)
• Pages: 579-585
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.825-826.579
• Online since: July 2015
• Authors: Thomas Seider*, Joerg Martin, Alexander Boeddicker, Julia Rühling, Daniel Wett, Daisy Nestler, Guntram Wagner, Arved Carl Huebler, Thomas Otto, Thomas Gessner
• Keywords: Flexographic Printing, Humidity Sensor, Hybrid Laminate, Lightweight Structures, Nano-/Micro-Composite

References

[1] P. Davies, F. Pomies, L.A. Carlsson, Influence of Water Absorption on Transverse Tensile Properties and Shear Fracture Toughness of Glass/polypropylene, J. of Comp. Mat. 30, 9 (1996) 1004-1019.

DOI: 10.1177/002199839603000903

[2] R. Selzer, K. Friedrich, Influence of water up-take on interlaminar fracture properties of carbon fibre-reinforced polymer composites, J. of Mat. Scien. 30 (1995) 334-338.

DOI: 10.1007/bf00354392

[3] A. Kootsookos, A.P. Mouritz, Seawater durability of glass- and carbon-polymer composites, Comp. Science and Techn. 64 (2004) 1503-1511.

DOI: 10.1016/j.compscitech.2003.10.019

[4] E.P. Gellert, D.M. Turley, Seawater immersion ageing of glass-fibre reinforced polymer laminates for marine applications, Composites: Part A 30 (1999) 1259-1265.

DOI: 10.1016/s1359-835x(99)00037-8

[5] B. M. Kulwicki, Humidity Sensors, J. Am. Ceram. Soc. 74, 4 (1991) 697-708.

[6] J. Martin, D. Piasta, J. Hammacher, M. Wegener, C. Dittrich, T. Otto, Sensitive Feuchte-sensoren auf der Basis von Nanokompositen, 2. GMM-Workshop Technologien und Werkstoffe der Mikrosystem- und Nanotechnik, Darmstadt, Proceedings (2010).

[7] P. M. Ajayan, L. S. Schadler, P. V. Braun, Nanocomposite Science and Technology, Wiley-VCH (2003).
