Electrospun Nanofibers Based on Polyvinyl Alcohol/Chitosan and its Stability in KOH Solution

Abstract:

Fabrication of nanofibers based on polyvinyl alcohol and chitosan (PVA/chitosan) has been carried out by means of electrospinning with focusing on beads formation and diameter variation due to effects of weight ratio variations of PVA/chitosan. For electrospinning solution, the PVA/chitosan with artios of 10:1, 10:2 and 10:3 w/w were dissolved in 1% acetic acid. In addition, stability testing of PVA/chitosan nanofibers in an electrolyte solution was performed by soaking the nanofiber mat in KOH solution. As results, the addition of chitosan concentration increased the pH, conductivity, and viscosity of the solution. Beads were potentially generated for low chitosan concentration. Furthermore, the effect of viscosity and conductivity on diameter of electrospun nanofibers is very significant and need to be optimized. The average diameter of electrospun nanofibers were found to be 160 ± 18 nm, 120 ± 12 nm, and 148 ± 26 nm, for weight ratios of PVA and chitosan 10:1, 10:2 and 10:3, respectively. In addition, no significant change in morphology after being soaked the electrospun PVA/chitosan nanofibers in KOH 40 wt% solution for 24 hours. It indicates that the electrospun PVA/chitosan nanofibers is stable in electrolyte solution which shows a high potential for electrolyte membrane in fuel cells application.

You might also be interested in these eBooks

Functional Properties of Modern Materials

View Preview

Info:

Periodical:

Materials Science Forum (Volume 827)

Pages:

321-325

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.827.321

Citation:

Cite this paper

Online since:

August 2015

Authors:

Kuwat Triyana*, M. Solihul Mu’min, Kuni Faizah, Yusril Yusuf, Ahmad Kusumaatmaja, Harsojo Harsojo

Keywords:

Acetic Acid, Bead, Chitosan, Electrospinning, Nanofibers, Weight Ratio

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] W.S. Khan, R. Asmatulu, M. Ceylan, and A. Jabbarnia, Recent Progress on Conventional and Non-Conventional Electrospinning Processes. Fibers and Polymers 14 (2013) 1235–1247.

DOI: 10.1007/s12221-013-1235-8

Google Scholar

[2] S. Kaur, S. Sundarrajan, D. Rana, R. Sridhar, R. Gopal, T. Matsuura, S. Ramakrishna, Review: the characterization of electrospun nanofibrous liquid filtration membranes, Journal of Materials Science 49, 18 (2014) 6143-6159.

DOI: 10.1007/s10853-014-8308-y

Google Scholar

[3] A.M. Abdelgawad, S.M. Hudson, and O.J. Rojas, Antimicrobial wound dressing nanofibersmats from multicomponent (chitosan/silver-NPs/polyvinyl alcohol) systems, Carbohydrate Polymers 100 (2014) 166-178.

DOI: 10.1016/j.carbpol.2012.12.043

Google Scholar

[4] W. S. Khan, R. Asmatulu, M. Ceylan, and A. Jabbarnia, Recent Progress on Conventional and Non-Conventional Electrospinning Processes, Fibers Polym. 14, 8 (2013) 1235-1247.

DOI: 10.1007/s12221-013-1235-8

Google Scholar

[5] L. Li and Y. -L. Hsieh, Chitosan bicomponent nanofibers and nanoporous fibers, Carbohydr. Res. 341, 3 (2006) 374-381.

DOI: 10.1016/j.carres.2005.11.028

Google Scholar

[6] Y. -T. Jia, J. Gong, X. -H. Gu, H. -Y. Kim, J. Dong, and X. -Y. Shen, Fabrication and characterization of poly (vinyl alcohol)/chitosan blend nanofibers produced by electrospinning method, Carbohydrate Polymers 67 (2007) 403–409.

DOI: 10.1016/j.carbpol.2006.06.010

Google Scholar

[7] U. S. Sajeev, A. K. Anand, D. Menon, and S. Nair, Control fo nanostructures in PVA, PVA/Chitosan blends and PCL through electrospinning, Bull. Mater. Sci. 31, 3 (2008) 343-351.

DOI: 10.1007/s12034-008-0054-9

Google Scholar

[8] K. Desai, K. Kit, J. Li, and S. Zivanovic, Morphological and Surface Properties of Electrospun Chitosan Nanofibers, Biomacromolecules 9, 3 (2008) 1000-1006.

DOI: 10.1021/bm701017z

Google Scholar

[9] A. Esmaeili, A.A. Beni, A novel fixed-bed reactor design incorporating an electrospun PVA/chitosan nanofibersmembrane, Journal of Hazardous Materials 280 (2014) 788-796.

DOI: 10.1016/j.jhazmat.2014.08.048

Google Scholar

[10] Harsojo, Susiani, K. Triyana, and H. Sosiati, A Simple Way of Producing Nano Anatase TiO2 in Polyvinyl Alcohol Fibers, Advanced Materials Research 896 (2014) pp.45-48.

DOI: 10.4028/www.scientific.net/amr.896.45

Google Scholar

[11] M.F.Z. Kadir, Z. Aspanut, S.R. Majid, and A.K. Arof, FTIR studies of plasticized poly(vinyl alcohol)–chitosan blend doped with NH4NO3 polymer electrolyte membrane, Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy 78, 3 (2011).

DOI: 10.1016/j.saa.2010.12.051

Google Scholar
