Superplastic Forming of a Complex Shape Automotive Component with Optimized Heated Tools

Abstract:

Superplastic forming (SPF) commonly requires industrial presses with an integrated large furnace able to uniformly heat the tools and the blank. In this work the feasibility to form via SPF an automotive component using a different heating approach was investigated. The heat is localized only where it is really needed embedding electric heating elements directly in the forming tools. Preliminary numerical simulations of the heating phase were aimed at calculating the electrical power and at choosing a suitable positioning of the heating elements. Further forming simulations were run to calculate the pressure profile. SPF experiments were finally conducted and sound components were obtained saving energy costs and using a common industrial press with lower investment costs.

• Periodical: Materials Science Forum (Volumes 838-839)
• Pages: 494-499
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.838-839.494
• Online since: January 2016
• Authors: Donato Sorgente*, Gianfranco Palumbo, Leonardo Daniele Scintilla, Riccardo Brivio, Gabriele Carozzi, Luigi Tricarico
• Keywords: Aluminium Alloy, Heated Forming Tools, Superplastic Forming

References

[1] G. Bernhart, P. Lours, T. Cutard, V. Velay, and F. Nazaret, Processes and equipment for superplastic forming of metals. Woodhead Publishing Limited, (2011).

DOI: 10.1533/9780857092779.1.49

[2] B. Swale, M. Pizzingrilli, and E. McCullagh, Superplastic Forming – Cost Effective, in Key Engineering Materials, 2010, vol. 433, p.41–47.

DOI: 10.4028/www.scientific.net/kem.433.41

[3] P. Wilson, C. Couzins-Short, H. Chesterton, and A. Jocelyn, Superplastic Forming and Diffusion Bonding: Current Cost, Value and Future Trends, in Key Engineering Materials, 2010, vol. 433, p.119–124.

DOI: 10.4028/www.scientific.net/kem.433.119

[4] J. Liu, M. -J. Tan, A. E. W. Jarfors, S. C. V Lim, K. -S. Fong, and S. Castagne, Greener manufacturing: Superplastic-like forming, J. Phys. Conf. Ser., vol. 379, p.012034, Aug. (2012).

DOI: 10.1088/1742-6596/379/1/012034

[5] N. Chandra, Constitutive behaviour of superplastic materials, Int. J. Non. Linear. Mech., vol. 37, no. December 2000, p.461–484, (2002).

[6] S. Rhaipu, The effect of rapid heat treatment on the high-temperature tensile behavior of superplastic Ti-6Al-4V, Metall. Mater. Trans. A, vol. 33, no. 1, p.83–92, (2002).

DOI: 10.1007/s11661-002-0007-7

[7] H. Karbasian and a. E. Tekkaya, A review on hot stamping, J. Mater. Process. Technol., vol. 210, no. 15, p.2103–2118, (2010).

DOI: 10.1016/j.jmatprotec.2010.07.019

[8] R. Neugebauer, T. Altan, M. Geiger, M. Kleiner, and a. Sterzing, Sheet metal forming at elevated temperatures, CIRP Ann. - Manuf. Technol., vol. 55, no. 2, p.793–816, Jan. (2006).

DOI: 10.1016/j.cirp.2006.10.008

[9] A. Jocelyn, A. Kar, A. Fanourakis, T. Flower, M. Ackerman, A. Keevil, and J. Way, Indirect Versus Direct Heating of Sheet Materials: Superplastic Forming and Diffusion Bonding Using Lasers, J. Mater. Eng. Perform., vol. 19, no. 4, p.527–532, Mar. (2010).

DOI: 10.1007/s11665-010-9619-z

[10] G. Bernhart, J. P. Arcens, and Y. Le Maoult, Innovative Superplastic Forming Based on In Situ Infra-Red Sheet Heating, in Materials Science Forum, 2013, vol. 735, p.415–421.

DOI: 10.4028/www.scientific.net/msf.735.415

[11] United States Patent Patent No.: US 6, 835, 254 B2, Hammar et al., Hot air convection; superplastic; cold working; electrical resistance, 28-Dec-(2004).

[12] United States Patent Patent No.: US 5, 410, 132, Gregg et al. Superplastic forming using induction heating, 25-Apr-(1995).

[13] J. Liu and K. Zhang, Resistance heating superplastic forming and influence of current on deformation mechanism of TA15 titanium alloy, Int. J. Adv. Manuf. Technol., vol. 76, no. 9–12, p.1673–1680, (2014).

DOI: 10.1007/s00170-014-6286-5

[14] D. Sorgente and L. Tricarico, Characterization of a superplastic aluminium alloy ALNOVI-U through free inflation tests and inverse analysis, Int. J. Mater. Form., vol. 7, p.179–187, (2014).

DOI: 10.1007/s12289-012-1118-3

[15] D. Sorgente and L. Tricarico, Pressure Profile Designing in Superplastic Forming Based on the Strain Rate and on Post-forming Properties, J. Mater. Eng. Perform., vol. 23, no. June, p.2025–2033, (2014).

DOI: 10.1007/s11665-014-1027-3
