Effects of Grinding Fluid Excited by Ultrasonic Vibration

Abstract:

Ultrasonic excited fluid has been researched for machining of hard-to-grind materials. Ultrasonic vibration is applied to grinding fluid by an ultrasonic oscillating comb-shape effecter with integrated nozzle. Grinding fluid discharges from a nozzle placed between the comb’s feet and passes through the vacant space between comb teeth. By this setup, flowing grinding fluid can be continuously excited by ultrasonic vibration. Based on the principle of an ultrasonic washing machine, impulsive force caused by cavitation bubble will reduce the adhesion of chips on the cutting face of grain and chip pockets. Some effects of ultrasonic excited grinding fluid have been recorded such as reducing grinding heat in the case of grinding for Titanium alloy and decreasing in grinding force, improving surface roughness in the case of grinding for Aluminum and stainless alloy. However, the reason of better grinding performance is still unknown. Therefore, experiments conducted with different type of grinding fluids with and without ultrasonic vibration are needed. Pure Titanium, which considered a hard-to-cut material, is chosen as work material. Grinding forces and grinding heat during grinding will be measured and evaluated to clarify the mechanism of ultrasonic excited grinding fluid.

• Periodical: Materials Science Forum (Volume 874)
• Pages: 308-312
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.874.308
• Online since: October 2016
• Authors: Hieu Nguyen Trung*, Jun Ishimatsu, Hiromi Isobe
• Keywords: Grinding Fluid, Grinding Force, Grinding Heat, Ultrasonic Machining, Ultrasonic Vibration

References

[1] Florian Feucht, Jens Ketelaer, Alexander Wolff , Masahiko Mori, Makoto Fujishima: Latest machining Technologies of Hard-to-cut Materials by Ultrasonic Machine Tool, Procedia CIRP 14 ( 2014 ) 148 – 152.

DOI: 10.1016/j.procir.2014.03.040

[2] Mohsen Ghahramani Nik, Mohammad R. Movahhedy, Javad Akbari: Ultrasonic-Assisted Grinding of Ti6Al4V Alloy, Procedia CIRP 1 ( 2012 ) 353 – 358.

DOI: 10.1016/j.procir.2012.04.063

[3] Prof. Dr. h. c. mult, Dr. -Ing. G. Spur, Dipl. -Ing. S. -E. Holl: Ultrasonic Assisted Grinding of Ceramics, Journal of Materials Processing Technology 62 (1996) 287-293.

DOI: 10.1016/s0924-0136(96)02422-3

[4] Ali Zahedi, Taghi Tawakoli, Javad Akbari: Energy aspects and workpiece surface characteristics in ultrasonic assisted cylindrical grinding of alumina–zirconia ceramics, International Journal of Machine Tools & Manufacture 90 (2015) 16–28.

DOI: 10.1016/j.ijmachtools.2014.12.002

[5] D. Bhaduria, S.L. Sooa, D.K. Aspinwalla, D. Novovicb, P. Hardenc, S. Bohrd, D. Martine: A study on ultrasonic assisted creep feed grinding of nickel based superalloys, Procedia CIRP 1 ( 2012 ) 359 – 364.

DOI: 10.1016/j.procir.2012.04.064

[6] Yongbo Wu, Syota Yokoyama, Takashi Sato, Weimin Lin, Toru Tachibana: Development of a new rotary ultrasonic spindle for precision ultrasonically assisted grinding, International Journal of Machine Tools & Manufacture 49 (2009) 933–938.

DOI: 10.1016/j.ijmachtools.2009.06.012

[7] Mohd Fauzi Ismail, Kazuhisa Yanagi, Hiromi Isobe: Geometrical transcription of diamond electroplated tool in ultrasonic vibration assisted grinding of steel, International Journal of Machine Tools & Manufacture 62 (2012) 24–31.

DOI: 10.1016/j.ijmachtools.2012.06.003

[8] J.Y. Shen n, J.Q. Wang, B. Jiang, X.P. Xu: Study on wear of diamond wheel in ultrasonic vibration-assisted grinding ceramic, Wear 332-333 (2015) 788–793.

DOI: 10.1016/j.wear.2015.02.047

[9] Zhiqiang Liang, Xibin Wanga, Yongbo Wub, Lijing Xiea, Zhibing Liua, Wenxiang Zhaoa, An investigation on wear mechanism of resin-bonded diamond wheel in Elliptical Ultrasonic Assisted Grinding (EUAG) of monocrystal sapphire Journal of Materials Processing Technology 212 (2012).

DOI: 10.1016/j.jmatprotec.2011.11.009

[10] J. Ishimatsu and H. Isobe: Grinding with Application of Ultrasonic Excited Grinding fluid-Experimental Verification of Grinding Performance Improvement on Al and SKS- , Proceeding of Japan Society of Abrasive Technology, (2012) 377-382.

DOI: 10.4028/www.scientific.net/kem.523-524.197

[11] J. Ishimatsu and H. Isobe: Grinding with Application of Ultrasonic Excited Grinding Fluid- Effects on Improvement of Surface Property and Inhibition of Grinding Heat for Pure Titanium-, Proceeding of Japan Society of Abrasive Technology, (2013).
