Mechanical Property and Characterization on Diamond Films Deposited on WC-Co Substrates

Abstract:

Cutting tools of WC-Co are widely used in cutting field. Nevertheless, its wear resistance and lifetime are not qualified for the high performance cutting. Therefore, diamond films are deposited on WC-Co substrates to overcome its disadvantages. In this paper we investigate the effects of the pretreatment on substrates and as-deposited WC-Co samples by using a hot filament chemical vapor deposition (HFCVD) reactor. Prior to deposition, the WC-Co substrates were submitted to surface roughening by Murakami reagent and to surface binder removal by Caro’ acid with varied durations. Surface roughness R_a determined by AFM varied from 110 to 279 nm. The diamond films are characterized by scanning electron microscopy (SEM) and Raman spectroscopy, whose results present a sharp peak at 1336 cm^-1 indicating sp³ diamond. The adhesion between the diamond films and substrates was evaluated by pull-off tests with the highest adhesion strength is 26.92 MPa. Cracked interface is characterized between diamond films and substrates, using SEM and energy dispersive spectroscopy (EDS) to analyze the adhesion performance.

• Periodical: Materials Science Forum (Volume 874)
• Pages: 333-338
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.874.333
• Online since: October 2016
• Authors: Hong Xiu Zhou*, Ming Lei Li, Bo Ya Yuan
• Keywords: Adhesion Strength, Diamond Film, HFCVD, Pretreatment, Scanning Electron Microscopy, WC-Co

References

[1] J.G. Zhang, X. Wang, B. Shen, F.H. Sun, Effect of boron and silicon doping on improving the cutting performance of CVD diamond coated cutting tools in machining CFRP, Int. J. Refract. Met. Hard Mater. 41 (2013) 285-292.

DOI: 10.1016/j.ijrmhm.2013.04.017

[2] B. Shen, F.H. Sun, H.G. Xue, M. Chen, Z.M. Zhang, Study on fabrication and cutting performance of high quality diamond coated PCB milling tools with complicated geometries, Surf. Eng. 25 (2009) 70-76.

DOI: 10.1179/026708408x334140

[3] R. Bian, E. Ferraris, N. He, D. Reynaets, Process investigation on meso-scale hard milling of ZrO2 by diamond coated tools, Precis. Eng. 38 (2014) 82-91.

DOI: 10.1016/j.precisioneng.2013.07.007

[4] T. Li, Q. Lou, J. Dong, Y. Wei, J. Zhou, J. Liu, Z. Zhang, F. Sun, Improved adhesion of diamond coating on cobalt-cemented tungsten carbide hardmetal by using pulsedUV-laser substrate surface pretreatment, Appl. Surf. Sci. 193 (2002) 102-119.

DOI: 10.1016/s0169-4332(02)00249-0

[5] Z.M. Zhang, H.S. Shen, F.H. Sun, X.C. He, Y.Z. Wan, Diamond Relat. Mater. 10 (2001) 33.

[6] S. Amirhaghi, H.S. Reehal, R.J.K. Wood, D.W. Wheeler, Surf. Coat. Technol. 135 (2001) 126.

[7] Y. Xie, R.J. Llewellyn, D. Stiles, Wear 250 (2001) 88.

[8] P. Niedzielski, S. Miklaszewski, P. Beer, A. Sokolowska, Diamond Relat. Mater. 10 (2001) 1.

[9] M.S. Raghuveer, S.N. Yoganand, K. Jagannadham, R.L. Lemaster, J. Bailey, Wear 253 (2002) 1194.

DOI: 10.1016/s0043-1648(02)00244-2

[10] R. Haubner, B. Lux, J. Phys. C 5 (1989) 169.

[11] B.S. Park, Y.J. Baik, K.R. Lee, K.Y. Eun, H.D. Kim, Diamond Relat. Mater. 2 (1993) 910.

[12] Y. Saito, K. Sato, S. Matsuda, H. Koinuma, Mater. Sci. 26 (1991) 2937.

[13] R. Haubner, S. Kubelka, B. Lux, M. Griesser, M. Grasserbauer, J. Phys. 5 (1995) 753-760.

[14] Jinqi Miao*, Jianhua Song, Yundong Xue, Yumei Tong, Weizhong Tang, Fanxiu Lu, Effect of a two-step pretreatment method on adhesion of CVD diamond coatings on cemented carbide substrates, Surface & Coatings Technology 187 (2004) 33-36.

DOI: 10.1016/j.surfcoat.2004.01.027

[15] Nemanich, J.T. Glass, G. Lucovsky, R.E. Schroder, J. Vac. Sci. Technol. A6 (1988) 1783.

[16] V.G. Ralchenko, A.A. Smolin, V.G. Pereverzev, E.D. Obraztsova, K.G. Korotoushenko, V.I. Konov, Y.V. Lakhotkin, E.N. Loubnin, Diamond deposition on steel with CVD tungsten intermediate layer, Diamond Relat. Mater. 4 (1995) 754-758.

DOI: 10.1016/0925-9635(94)05299-9

[17] Riccardo Polini, Michele Delogu, Giancarlo Marcheselli, Adherent diamond coatings on cemented tungsten carbide substrates with new Fe/Ni/Co binder phase, Thin Solid Films 494 (2006) 133 - 140.

DOI: 10.1016/j.tsf.2005.08.217

[18] Gil Cabral, Jan Gäbler, Jörn Lindner, José Grácio, Riccardo Polini, A study of diamond film deposition on WC-Co inserts for graphite machining: Effectiveness of SiC interlayers prepared by HFCVD, Diamond & Related Materials 17 (2008) 1008-1014.

DOI: 10.1016/j.diamond.2008.03.017
