The Effects of Interfacial Heat Transfer Coefficient on the Microstructure of High-Pressure Die-Cast Magnesium Alloy AM60B

Abstract:

This paper describes the details of a quantitative experimental and numerical study on the influence of solidification conditions, including the apparent interfacial heat transfer coefficient (IHTC) between the die and solidifying metal, on the resulting local microstructure. Multiple runs of the commercial casting simulation package, ProCASTTM, are used to model the mold filling and solidification events employing a range of IHTC values. The simulation results are used to estimate the centreline cooling curve at various locations through the casting. The centreline cooling curve, together with the die temperature and the thermodynamic properties of the alloy are then used as inputs to compute the solution to the Stefan problem of a moving phase boundary, thereby providing the through-thickness cooling curves at each chosen location of the casting. Finally, the local cooling rate is used to calculate the resulting grain size and skin thickness via previously established relationships. A comparison of the predicted and experimentally determined grain size profiles enables the determination of the apparent IHTC, which, in this study, was approximately 12000 W/m²·K. Additional useful observations from the numerical study suggest that the IHTC has a significant influence on the skin thickness and grain size in both the skin and core regions of the casting, while the effect of die temperature is limited to influencing the skin grain size only.

• Periodical: Materials Science Forum (Volume 879)
• Pages: 1755-1759
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.879.1755
• Online since: November 2016
• Authors: Pouya Sharifi*, Kumar Sadayappan, Jeffrey T. Wood
• Keywords: Heat Transfer Coefficient, High Pressure Die Casting, Magnesium Alloy AM60B

References

[1] A.K. Dahle et al, Solidification of cast magnesium alloy, J. Light Metals 1 99–103(2001).

[2] J.P. Weiler et al, Variability of skin thickness in an AM60B magnesium alloy die-casting, Materials Science and Engineering A, A419 (2006), 297-305.

DOI: 10.1016/j.msea.2006.01.034

[3] P. Sharifi et al, Predicting the flow stress of high pressure die cast magnesium alloys, Journal of Alloys and Compounds 605 (2014) 237–243.

DOI: 10.1016/j.jallcom.2014.03.043

[4] P. Sharifi et al, Process-structure-property correlations for HPDC AM60B, TMS (2015 )Pages 351-356.

DOI: 10.1007/978-3-319-48185-2_65

[5] P. Sharifi et al, A novel non-experimental prediction of microstructure-mechanical relationships for magnesium alloy AM60, submitted to Materials and Design (2016).

[6] G. Zhi-peng et al., Determination of the heat transfer coefficient at metal–die interface of high pressure die casting process of AM50 alloy, International Journal of Heat and Mass Transfer 51 (2008) 6032–6038.

DOI: 10.1016/j.ijheatmasstransfer.2008.04.029
