Structural Behaviour of Beam with HDPE Plastic Balls Subjected to Flexural Load

Abstract:

This paper presents the structural behaviour of reinforced concrete beam embedded with high density polyethylene balls (HDPE) subjected to flexural load. The HDPE balls with 180 mm diameter were embedded to create the spherical voids in the beam which lead to reduction in its self-weight. Two beam specimens with HDPE balls (RC-HDPE) and one solid beam (RC-S) with dimension 250 mm x 300 mm x 1100 mm were cast and tested until failure. The results were analysed in the context of its ultimate load, load-deflection profile, and crack pattern and failure mode. It was found that the ultimate load of RC-HDPE was reduced by 32% compared to RC-S beam while the maximum deflection at its mid span was increased by 4%. However, RC-HDPE is noticed to be more ductile compared to RC-S beam. Both types of beams experienced flexure cracks and diagonal tension cracks before failure.

• Periodical: Materials Science Forum (Volume 889)
• Pages: 270-274
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.889.270
• Online since: March 2017
• Authors: Noridah Mohamad, Wan Inn Goh*, Abdul Aziz Abdul Samad, A. Lockman, Anas Alalwani
• Keywords: Deflection, Flexural Load, HDPE Plastic Balls, Self-Weight, Structural Behaviour

References

[1] N. Mohamad, W. Omar, R. Abdullah, Precast Lightweight Foamed Concrete Sandwich Panel (PLFP) Tested under Axial Load: Preliminary Results, Advanced Materials Research, Vols. 250-253, pp.1153-1162. (2011).

DOI: 10.4028/www.scientific.net/amr.250-253.1153

[2] Md Azree Othman Mydin, Potential of Using Lightweight Foamed Concrete in Composite Load-Bearing Wall Panels in Low-Rise Construction, Concrete Research Letter. Vol. 2 (2), (2011).

[3] N. Mohamad, H. M. Muhammad, Testing of Precast Lightweight Foamed Concrete Sandwich Panel with Single and Double Symmetrical Shear Truss Connectors under Eccentric Loading, Advanced Materials Research, Vols. 335-336, pp.1107-1116, (2011).

DOI: 10.4028/www.scientific.net/amr.335-336.1107

[4] W. I. Goh, N. Mohamad, R. Abdullah, & A. A. A. Samad, Compression Test and Finite Element Analysis of Foamed Concrete Cube, Journal of Engineering and Technology (JET), Vols 5-1, pp.1-10.

[5] W. I. Goh, N. Mohamad, R. Abdullah, & A. A. A. Samad, Overview of Empirical Equation Prediction for Ultimate Axial Load of Precast Lightweight Foamed Concrete Sandwich Panel (PLFP), ARPN Journal of Engineering and Applied Sciences, Volume 11, Issue 4, 2016, pp.2366-2371.

DOI: 10.4028/www.scientific.net/amr.250-253.1153

[6] Kang, T. H.K., Kim, W., Kwak, Y. K., & Hong, S. G, The choice of recycled concrete aggregates for flexural members, Proceedings of 18th International Association for Bridge and Structural Engineering Congress on Innovative Infrastructures, Seoul, Korea. (2012).

DOI: 10.2749/222137912805111032

[7] Sato, R., Maruyama, I., Sogabe, T., & Sogo, M. Flexural Behaviour of Reinforced Recycled Concrete Beams., Journal of Advanced Concrete Technology, 5, 1, 43–61. (2007).

DOI: 10.3151/jact.5.43

[8] M. Kampner, R. M. Deacon, A. R. Marder, Failure analysis of an aluminium sandwich panel skin from the space shuttle Columbia, Journal of Failure Analysis and Prevention. Volume 6, Issue 1, 46-50. (2006).

DOI: 10.1361/154770206x86536

[9] K. Kantha Rao, K. Jayathirtha Rao, A. G. Sarwade, B. Madhava Varma, Bending Behaviour of Aluminum Honey Comb Sandwich Panels, International Journal of Engineering and Advanced Technology (IJEAT) ISSN: 2249 – 8958, Volume-1, Issue-4, (2012).

[10] M. Mustafa Al Bakri, S. Mohammad Tamizi, A. R. Rafiza, Y. Zarina, Investigation of HDPE Plastic Waste Aggregate on the Properties of Concrete, Journal of Asian Scientific Research, 1(7), pp.340-345, (2011).

[11] Saifee Bhagat , Dr. K. B. Parikh, Comparative Study of Voided Flat Plate Slab and Solid Flat Plate Slab, International Journal of Innovative Research and Development, Vol. 3, Issue 3. (2014).

[12] Lan Chung, Sang-Hyun Lee, Seung-Ho Cho, Sung-Sik Woo, Kyoung-Kyu Choi, Investigations on Flexural Strength and Stiffness of Hollow Slabs, Journal of Advances in Structural Engineering, Vol. 13, No. 4, (2009).

DOI: 10.1260/1369-4332.13.4.591
