In Situ Synthesis and Structural Design of Ti/TiC Functionally Graded Materials

Abstract:

In this paper, the metal/ceramic functionally graded composites are prepared. The thermal stress of TiC/Ti functionally graded composites are simulated by Abaqus finite element analysis software to study the influence of the number of layers, the gradient layer thickness and the gradient of distribution index.The optimal structural parameters of the TiC/Ti functional gradient composites are obtained as the number of layers of 6 and the gradient distribution index 0.8. According to the optimized structural parameters, Ti and C powders are mixed by high-energy ball milling, then the TiC/Ti functional gradient composites are prepared by spark plasma sintering. The gradient distribution of composition and microstructure in TiC/Ti functionally graded composites are achieved, which can solve the problem of mismatch for the physical properties between the metal and the ceramic in the composite material.

• Periodical: Materials Science Forum (Volume 913)
• Pages: 515-521
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.913.515
• Online since: February 2018
• Authors: Qi Jin, Xue Ping Ren, Hong Liang Hou, Yan Ling Zhang, Hai Tao Qu*
• Keywords: Finite Element Analysis, Functionally Graded Materials, In Situ Synthesis, Optimal Structure Design

References

[1] Qin K C, Feng K Q, Sun L, et al. Analysis of Thermal residual stresses in TiC coatings on gradient cemented carbide [J], Journal of Sichuan University (Engineering Science Edition), 2012, 1.

[2] Fan S T, Tang H B, Zhang S Q, et al. Finite Element Analysis of Thermal Stress for Gradient Composite [J]. Material & Heat Treatment, 41(4) (2012) 106-109.

[3] Gang J, Hideo A. Residual thermal stresses in muhi layered functionally graded material plate [J]. Materials Science Research International, 9(2) (2003) 125-130.

[4] Cao P, Liu B, Yin K, et al. Optimization design and residual thermal stress analysis of PDC functionally graded materials [J]. Journal of Zhejiang University SCIENCE A, 7(8) (2006) 1318-1323.

DOI: 10.1631/jzus.2006.a1318

[5] Ye D L, Practical Inorganic Thermodynamics Data Sheet [M]. Beijing: Metallurgical Industry Press, (2002).

[6] Li Y K, Wang Y, Han W B. Structure Optimization of PSZ/Mo Functionally Gradient Materials [J]. Materials for Mechanical Engineering, 27(2) (2003) 14-16.

[7] Liu B B, Xie J X. Design, fabrication and evaluation of W-Cu functionally graded materials [J]. Materials Science and Engineering of Powder Metallurgy, 15(5) (2010) 413-420.

[8] Zou J P, Ruan J M, Zhou Z C, Design, preparation and property evaluation of functionally graded materials. [J], 10(2) (2005) 78-87.

[9] PINTSUK G, BRUNINGS S E, DORING J E, et al. Development of W/Cu-functionally graded materials [J]. Fusion Engineering and Design, 66(68) (2003) 237-240.

DOI: 10.1016/s0920-3796(03)00220-5

[10] Cao W B, Ge C C, Li J T, Wu A H. Residual Thermal Stress Analysis of Symmetrically Compositional FGM [J]. Powder Metallurgy Industry, 12(2) (2002) 13-15.

[11] Pagget J W, Drake E F, Krawitz A D, et al. Residual stress and stress gradients in polycrystalline diamond compacts. [J]. International Journal of Refractory Metals and Hard Material, 20(3) (2002) 187-194.

DOI: 10.1016/s0263-4368(01)00077-4

[12] Zhang K Y, Zhang J G, Lyu Y B. Thermal Stress Analysis in Ceramic/Metal Functionally Gradient Material Plate. [J]. Journal of Zhanjiang Ocean University, 17(1) (1997) 34-38.

[13] Huang L X, Yang Z Z, Zhang X L, Yang M. An Analysis of Functionally Graded Materials by the Isoparametric Graded Finite Element Method Based on ABAQUS. [J]. FRP /CM, (2) (2014) 33-37.

DOI: 10.2514/6.2022-1488.vid

[14] Li Zhenxi, Zhang Tongjun, Li Xingguo. Finite Element Analysis of Thermal Residual Stresses in Al2O3 Ti System Functionally Gradient Material. Journal of Materials Engineering, 0(3) (1998) 11-16.

[15] Ling Y H, Bai X D, Li J T. Optimum Design of W/Cu Functionally Graded Material for Thermal Stress Mitigation. [J]. Rare Metal Materials and Engineering, 32(12) (2003) 976 -980.
