Implementation and Use of a Laser-Ultrasonic System in a Deformation- and Quenching Dilatometer

Abstract:

State of the art of in-situ analysis on grain structure of metals during thermal and stress treatment is done by observation of the probe in a thermomechanical treatment system. Potential analysis methods are high energy x-ray scattering (e.g. in a synchrotron) or laser-ultrasonics (LUS). The most commonly used thermomechanical system, is the so called “Gleeble” from Dynamic Systems Inc., which is able to heat and load the material in a quite fast manner with extremely high heating rates, very high forces and fast force changes. There is a wide area of research and applications, though, where these capabilities are not fully required, a less complex deformation-and quenching dilatometer would often be sufficient. In this paper we will show the implementation of a LUS system in such a dilatometer and compare it to the “all inclusive” Gleeble system, pointing out benefits and downsides on different aspects, like the technical specifications, the needed footprint and more. A sketch of the full system and the beam path will show the general idea on the implementation of the LUS system into the dilatometer. We will also present first results of a thermal treatment on a metal sample suited for grain structure and phase transition analysis.

• Periodical: Materials Science Forum (Volume 941)
• Pages: 2423-2428
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.941.2423
• Online since: December 2018
• Authors: Edgar Scherleitner*, Bernhard Reitinger, Markus Gruber, Peter Burgholzer
• Keywords: Dilatometer, Gleeble, In Situ Grain Structure Analysis, Laser Ultrasonics, Thermo-Mechanical Simulator, Ultrasound

References

[1] M. Boenisch, A. Panigrahi and e. al., Giant thermal expansion and α-precipitation pathways in Ti-alloys,, Nature Communications, no. 1429, (2017).

[2] S. A. McDonald, P. Reischig, C. Holzner, E. M. Lauridsen, P. J. Withers, A. P. Merkle and M. Feser, Non-destructive mapping of grain orientations in 3D by laboratory X-ray microscopy,, in Scientific Reports, www.nature.com, (2015).

DOI: 10.1038/srep14665

[3] A. Moreau, S. E. Kruger, M. Côte and P. Bocher, In-Situ Monitoring of Microstructure during Thermomechanical Simulations using Laser-Ultrasonics,, in Laser Ultrasonics, Montreal, Canada, (2008).

[4] M. Dubois, A. Moreau, A. Dawson, M. Militzer and B. J. F, Laser Ultrasonic Measurement of Microstructure Evolution during Metals Processing,, in RTO, MP-9, (1998).

[5] E. Lindh-Ulmgren, D. Artymowicz and B. Hutchinson, Application of Laser-Ultrasonics (LUS) to Studies of Recrystallization in Metals,, Joint International Conference on Recrystallisation and Grain Growth, pp.577-581, (2001).

DOI: 10.4028/www.scientific.net/msf.467-470.1353

[6] P. P. Nanekar and B. K. Shah, Characterization of Metal Properties by Ultrasonics,, BARC Newsletter, no. 249, (2003).

[7] A. Moreau, Laser-Ultrasonic Characterization of the Microstructure of Aluminum,, Material Science Forum, pp.1373-1378, (2006).

[8] M. Militzer, T. Garcin and W. J. Poole, In-situ measurements of grain growth and recrystallization by laser ultrasonics,, International Conference on Recrystallisation and Grain Growth, (2013).

DOI: 10.4028/www.scientific.net/msf.753.25

[9] M. Dubois, A. Moreau and F. Bussière, Ultrasonic velocity measurements during phase transformation in steels using laser ultrasonics,, Journal of Applied Physics, vol. 89, no. 11, pp.6487-6495, (2001).

DOI: 10.1063/1.1363681

[10] http://gleeble.com/lumet.html, LUMet-Laser-Ultrasonic Sensor for In-Situ Metallurgical Studies,, White Paper, (2016).

[11] P. Bariobero-Vila, G. Requena, T. Buslaps and e. al., Role of element partitioning on the alpha - beta phase transformation kinetics of a bi-modal Ti6Al6V2Sn alloy during continuous heating.,, Journal of Alloys and Compounds, vol. 626, pp.330-339, (2015).

DOI: 10.1016/j.jallcom.2014.11.176

[12] J. P. Monchalin and J. D. Aussel, Ultrasonic Velocity and Attenuation Determination by Laser-Ultrasonics,, Journal of Nondestructive Evaluation, vol. 9, no. 4, (1990).

DOI: 10.1007/bf00565639

[13] S. Sarkar, A. Moreau, M. Militzer and W. Poole, Evolution of austenite recrystallization and grain growth using laser-ultrasonics,, Metallurgical and Materials Transactions, vol. 39, no. 4, pp.897-907, (2008).

DOI: 10.1007/s11661-007-9461-6

[14] I. Hinterlechner, P. Barriobero-Vila, B. Reitinger, T. Fromherz, G. Requena and P. Burgholzer, In-situ monitoring of alpha to beta phase transformation in Ti-6Al-6V-2Sn using laser ultrasonics,, Taylor & Francis, 2017. [Online].

DOI: 10.1080/10589759.2017.1356925
