Laser Welding of Titanium Alloys with an Yb: YAG Disk Source

Abstract:

In this paper, the laser welding of thin titanium sheet in a butt joint configuration are investigated using a continuous Yb: YAG disk source, with high beam quality and a particular fiber configuration, enable to provide a broad range of beam diameters with different intensity distribution. The thermal efficiency of the laser process is discussed as a function of the fiber type. The weldability results for the CP Ti grade 2 and the Ti-6Al-4V titanium alloy are expressed in terms of full penetration, and correct bead geometry (NF L06-395-2000). Full penetration welds are easily achieved with the core fiber, but the outer fiber produces welds with limited geometric defects. Butt joints microstructure consists of an acicular α phase in the fusion zone for CP Ti, and a martensitic α’ phase for the Ti-6Al-4V alloy. Tensile test results confirm a similar or slightly higher joint strength for the full penetration welds, compared with the parent metal.

• Periodical: Materials Science Forum (Volume 941)
• Pages: 845-850
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.941.845
• Online since: December 2018
• Authors: Jean Denis Beguin, Valentin Gazagne, Yannick Balcaen, Joel Alexis, Eric Andrieu
• Keywords: Full Penetration Weld, Geometric Defects, Titanium Weldability, Welding Efficiency, Yb: YAG Disk Source

References

[1] A. Squilace, U. Sprisco, S. Ciliberto, A. Astarita, Effect of welding parameters on morphology and mechanical properties of Ti-6Al-4V laser beam welded butt joints, Journal of Materials Processing Metallurgy, 212 (2012) 427-436.

DOI: 10.1016/j.jmatprotec.2011.10.005

[2] R.S. Sharma, P. Molian, Weldability of advanced high strength steels using Yb: YAG disk laser, Journal of Materials Processing Technology, 211 (2011) 1888-1897.

DOI: 10.1016/j.jmatprotec.2011.06.009

[3] A. Costa, R. Miranda, L. Quintino, D. Yapp, Analysis of beam material interaction in welding of titanium with fiber lasers, Materials and manufacturing processes, 22 (2007) 798-803.

DOI: 10.1080/10426910701446671

[4] X. Cao, M. Jahazi, Effect of welding speed on butt joint quality of Ti-6Al-AV alloy welded using a high-power Nd:YAG laser, Optics and Lasers in Engineering, 47 (2009) 1231-1241.

DOI: 10.1016/j.optlaseng.2009.05.010

[5] A-M El-Batahgy, T. DebRoy, Nd-YAG Laser Beam and GTA welding of Ti-6Al-4V, International Journal of Engineering and Technical Research, 2 (2014) 43-50.

[6] A. Patschger, J. Bliedtner, J.P Bergmann, Approaches to increase process efficiency in laser micro welding, Physics Procedia, 41 (2013) 592-602.

DOI: 10.1016/j.phpro.2013.03.121

[7] L. Quintino, A. Costa, R. Miranda, D. Yapp, V. Kumar, Welding with high power lasers-A preliminary study, Materials and design, 28 (2007) 1231-1237.

DOI: 10.1016/j.matdes.2006.01.009

[8] N. Kashaev, D. Pugachev, V. Ventzke, Microstructure and mechanical performance of autogenously fiber laser beam welded Ti-6242 butt joints, Material Science & Engineering, A 694 (2017)110-120.

DOI: 10.1016/j.msea.2017.03.115
