Effects of Gas Film Hole on Mechanical Property and Oxidative Damage of Turbine Blades

Abstract:

With the development of aero-engine with high specific flux, high thrus-weight ratio, and high turbine inlet temperature, it is an effective way to improve the cooling efficiency by designing dense gas film holes on the blade surface of the turbine blades, especially at the intake side. However, the introduction of gas film holes destroys the geometrical integrity of the blade structure, resulting in a multiaxial high stress state of the blade material around the small holes, which seriously affects the strength and life of the cooling blades. In addition, the geometry design of the gas film holes also directly affects the temperature and the oxidation rate of the turbine rotor blades. In this paper, the researches on the mechanical properties and oxidative damage of the gas film holes at home and abroad in recent years have been systematically introduced. The effects of gas film holes on the durability and fatigue properties, the high temperature oxidation behavior of single crystal superalloys, and the thin-walled effect of oxidative damage of gas film holes have been systematically described.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 421-425
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.421
• Online since: January 2019
• Authors: Chun Yan Hu, Zhi Qiang Kong, Xin Ling Liu, Chun Hu Tao
• Keywords: Gas Film Hole, Mechanical Properties, Oxidative Damage, Thin-Wall Effect, Turbine Blade

References

[1] D. Lakehal, G.S. Theodoridis, W. Rodi. Three-dimensional flow and heat transfer calculations of film cooling at the leading edge of a symmetrical turbine blade model[J]. International Journal of Heat and Fluid Flow, 2001, 22(2): 113-122.

DOI: 10.1016/s0142-727x(00)00084-9

[2] Y.J. Kim, S.M. Kim. Influence of shaped injection holes on turbine blade leading edge film cooling[J]．International Journal of Heat and Mass Transfer, 2004, 47(2): 245-256.

DOI: 10.1016/j.ijheatmasstransfer.2003.07.008

[3] C.Y. Hu, Y.M. Xu, X.L. Liu, et a1. Stress rupture behavior of modeling specimen with cooling holes of single crystal superalloy DD6[J]. Failure Analysis and Prevention, 2007, 12(1): 38-42.

[4] R.A. Kupkovits, R.W. Neu. Thermo-mechanical fatigue of a directionally-solidified Ni-based superalloy: smooth and cylindrically-notched specimens[J]. International Journal of Fatigue, 2010, 32(8): 1330-1342.

DOI: 10.1016/j.ijfatigue.2010.02.002

[5] S.G. Dai, L. Yin, H. Qing. Creep life study on the modeling specimen of DD6 single crystal cooling turbine blade[J]. Gas Turbine Experiment and Research, 2011 (4): 36-40.

[6] H. Qing, H.F. Jiang, W.D. Wen. Study on the creep behavior of model specimens of nickel-based single crystal air-cooled blades[J]. Journal of Aerospace Power, 2007, 22(5): 773-777.

[7] Q.M. Yu, Y.L. Wang, Z.X. Wen, et al. Notch effect and its mechanism during creep rupture of nickel-base singlecrystal superalloys[J]. Materials Science and Engineering A, 2009, 520: 1-10.

DOI: 10.1016/j.msea.2009.04.060

[8] P. Lukas, P. Preclik, J. Cadek. Notch effects on creep behaviour of CMSX-4 superalloysingle crystals[J]. Materials Science and Engineering A, 2001, 298: 84-89.

DOI: 10.1016/s0921-5093(00)01288-0

[9] K. Koji. Effect of plastic anisotropy on the creep strength of single crystals of a nickel-based superalloy[J]. Metallurgical and Materials Transactions A, 2000, 31(2): 421-430.

DOI: 10.1007/s11661-000-0279-8

[10] D.Q. Shi, J. Huang, X.G. Yang, et al. Effects of crystallographic orientations and dwell types on low cycle fatigue and life modeling of a SC superalloy[J]. International Journal of Fatigue(S0142-1123), 2013, 49: 31-39.

DOI: 10.1016/j.ijfatigue.2012.12.005

[11] X.P. Lu, Z.X. Wen, Z.F. Yue. Low cycle fatigue fracture mechanism of a modeling specimen with cooling film hole of DD6 single crystal superalloy[J]. Rare Metal Materials and Engineering, 2015, 44(5): 1173-1176.

[12] M.H. Li, X.F. Sun, J.G. Li, et al. Oxidation behavior of a single-crystal Ni-base superalloy in air. I:at 800 and 900℃[J]. Oxidation of Metals, 2003, 59(5/6): 591-605.

[13] A. Akhtar, M.S. Hook, R.C. Reed. On the oxidation of the third-generation single crystal superalloy CMSX-10[J]. Metallurgical and Materials Transactions A, 2005, 36: 3001-3017.

DOI: 10.1007/s11661-005-0073-8

[14] C.M. Younes, G.C. Allen, J.A. Nicholson. High temperature oxidation behaviour of single crystal superalloys RR3000 and CMSX-4[J]. Corrosion Engineering Science and Technology, 2007, 42(1): 80-88.

DOI: 10.1179/174327807x159925

[15] M. Doner, J.A. Hechler. Effects of section thickness and orientation on creep rupture properties of two advanced single crystal alloys[C]//Society of Automotive Engineers Inc. SAE Technical Paper 851785, Warrendale: (1985).

DOI: 10.4271/851785

[16] P. Kofstad. Defects and transport properties of metal oxides[J]. Oxidation of Metals, 1995, 44(1/2): 3-27.

[17] Y.R. Zheng. Size effects of thin section for single crystal turbine blade superalloys[J]. Journal of materials engineering, 2007, 7: 74-77.

[18] Z.H. Zhang, J.J. Yu, F. Shi, et al. Influence of thin wall on the tensile properties of DD499 single crystal superalloy[J]. Foundry, 2014, 63(8): 781-787.

[19] C.K. Yu, J.J. Yu, F.J. Zhang, et al. Influence of thin wall on the stress rupture properties of DD49 single crystal superalloy[J]. Foundry, 2014, 63(5): 479-483.
