Microstructure and Mechanical Properties of Aluminum Alloy/High Strength Steel Double Beam Laser Deep Penetration Welded Joint

Abstract:

A new dual beam laser deep penetration welding technology for lap joint of 1.5 mm thick aluminum alloy and high strength steel was explored in this paper, and the effects of three different beam energy ratios (R_S=0.25,0.33,0.5) on weld formation, interface microstructure and mechanical properties were studied. The result shows that under certain conditions of other parameters, double beam laser deep penetration welding process can be applied to lap joint of aluminum alloy / high strength steel with good weld shape when R_S=0.25,0.33,0.5. As R_S increases from 0.25 to 0.5, the penetration of the weld reduces from 575 μm to 424.2μm, the thickness of intermetallic compound (IMC) layer at the interface between aluminum alloy and weld metal reduces from 3.4 μm to 2.5 μm, the average microhardness of the IMC layer decreases from 771.1 HV to 571.9 HV, the mechanical resistance of the joint raises from 95.7N/mm to 115.2N/mm. When R_S=0.5, double beam laser deep penetration welding of aluminum alloy / high-strength steel joints has the highest mechanical resistance of joints, because of the relatively good plastic ductility of the joint.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 448-457
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.448
• Online since: January 2019
• Authors: Hong Xi Chen, Li Cui, Dong Qi Lu, Yao Qing Chang, Xu Xia, Ding Yong He
• Keywords: Aluminum Alloy, Dual-Laser Beam, High Strength Steel Dissimilar Alloy, Intermetallic Compound (IMC), Laser Deep Penetration Welding, Mechanical Resistance

References

[1] Lei Zhen, Qin Guoliang, Lin Shangyang, Research and Developments of Dissimilar Metals Welding of Aluminum and Steel of Aluminum and Steel, J. Welding & Joining. 4 (2006) 16-20.

[2] Song Jianling, Lin Sanbao, Yang Chunli, M. Guangchao, Research and Development on arc Welding-brazing of Dissimilar Metals between Aliuminum and Steel, J. Welding & Joining. (2008) 6-9.

[3] Chen Shuhai, Zhang Mingxin, Li Meng, Huang Jihua, Numerical simulation of fiber laser welding-brazing of Fe /Al dissimilar metals, J. Welding & Joining.36 (2015) 21-24.

[4] Zhou Dianwu, Peng Yan, Xu Shaohua, Liu Jinshui. Acta Metall Sin, 49 (2013) 959.

[5] Zhou Dianwu, Wu Ping, Peng Li, Zhang Yi, Chen Genyu. Chin J NonferrousMet, J. 22 (2012) 1738.

[6] Ma J J, Masoud H, Carlson B, Kovacevic R. Mater Des, 58 (2014) 390.

[7] Chen Shuhai, Huang Jihua, Yang Dongdong, Ma Ke, Zhang Hua. Trans ChinaWeld, 33 (2012) 9.

[8] Wang Tao, Zhou Dianwu, Peng Yan, Zhang Yi, Chen Genyu, Steel-to-Alminum Fiber Laser Butt Welding with Si Powder Pre-Filling, J.Chinese Journal of lasers, 39 (2012) 106-113.

DOI: 10.3788/cjl201239.0303009

[9] Li Qiaoyan, Luo Yu, Wang Yajun, Chen Li, Microstructure and Mechanical Properties of Twin Spot Laser Welding of 5052 Aluminum, J. Transactions of the China Welding Institution, 28 (2007) 105-108.

[10] Li Liqun, Chen Yanbin, Tao Wang, Research on Dual-Beam Welding Characteristics of Aluminum Alloy, J. Chinese Journal of lasers, 35 (2008) 1783-1788.

DOI: 10.3788/cjl20083511.1783

[11] Meco S, Pardal G, Ganguly S, et al. Application of laser in seam welding of dissimilar steel to aluminium joints for thick structural components, J. Optics and Lasers in Engineering, 67 (2015) 22-30.

DOI: 10.1016/j.optlaseng.2014.10.006

[12] Lei Zhenglong, Chen Yanbin, Lv Tao, Effect of Energy Arrangement on Temperature Field and Stress Field in Dual-Beam Laser Welding Process with Filler Wire, J. Transactions of the China Welding Institution, 33 (2012) 83-88.

[13] Zhou Dianwu, Qiao Xiaojie, Zhang Lijuan, Li Sheng, Parameters optimization of laser welding process of galvanized steel and 6016 aluminum alloy based on BP neural network and its microstructure and mechanical properties, J. The Chinese Journal of Nonferrous Metals, 24 (2014) 678-688.

[14] Liu Shunhong, Wan Pengten, Hu Liangguo, Li Zhiyuan, Yu Wei, Study on Numerical of the Temperature Field in Laser Welding of Steel Sheet, J. Electric Welding Machine, 31 (2001) 16-19.

[15] Zhang Xinge, Anaysis of Temperature Field and Stress and Streain Field in Dual Beam Laser Welding Different Thickness Plates, D. Harbin Institute of Technology, (2006).

[16] Li Qiaoyan, Luo Yu, Wang Yajun, Chen Li, Microstructure and Mechanical Properties of Twin Spot Laser Welding of 5052 Aluminum, J. Transactions of the China Welding Institution, 28 (2007) 105-108.

[17] Pang S, Chen W, Zhou J, et al. Self-consistent modeling of keyhole and weld pool dynamics in tandem dual beam laser welding of aluminum alloy, J. Journal of Materials Processing Technology, 217 (2015) 131-143.

DOI: 10.1016/j.jmatprotec.2014.11.013

[18] BAHADUR A, MOHANTY O N. Structural studies of hot dip aluminized coatings on mild steel, J. Materials Transactions, 32 (1991) 1053-1061.

DOI: 10.2320/matertrans1989.32.1053
