Corrosion Strength Analysis of Casing in Offshore Thermal Recovery Wells

Abstract:

Corrosion is a common problem in offshore oil and gas wells, especially in thermal recovery wells, which will greatly affect the residual strength of casing strings. Field data show that the corrosion pattern of casing is mainly pitting, local corrosion and uniform corrosion, of which pitting is the most common. For this reason, based on the engineering practice of thermal recovery well casing corrosion, the dynamic changes of wellbore temperature and pressure during the gas production process of thermal recovery wells are considered, and the numerical model of casing corrosion under transient temperature and pressure coupling is established. The influence of corrosion morphology and corrosion depth on the residual strength of the casing is analyzed. The transient stress variation law of the corroded casing is studied. The results show that: (1) Under the same corrosion depth, both pitting and uniform corrosion will reduce the residual internal pressure and external extrusion strength of the casing string, and the degree of influence is similar. The effect of uniform corrosion on the residual tensile strength of the casing string is larger than pitting and local corrosion; (2) the residual strength of the casing decreases linearly with the increase of the corrosion depth of the casing; (3) the stress of the corrosion part of the casing shows a significant dynamic change, in the initial stage of steam injection, casing stress rises rapidly at the corrosion position, and then the rate at which the casing stress rises is slowed, which tends to cause fatigue damage to the casing. The research results have reference significance for the assessment of the service status of offshore thermal recovery well casings.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 956-964
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.956
• Online since: January 2019
• Authors: Jun Li*, Xue Feng Song, Gong Hui Liu, Yan Xi, Wei Lian, Tao Huang
• Keywords: Casing Corrosion, Offshore Thermal Recovery Well, Pitting Corrosion, Residual Strength, Temperature-Pressure Coupling

References

[1] Lin G, Bai Z, Zhao X, et al. Effect of temperature on the morphology of carbon dioxide corrosion products, ACTA PETROLEI SINICA. 25 (2004) 101-105.

[2] Gong J, Wang Q, Liu Y. Analysis of the contribution of different forms of sulfides to the thermal recovery of heavy oil hydrogen sulfide (in Chinese), Petroleum Geology and Recovery Efficiency. 22 (2015) 93-96.

[3] Chen Y, Shi F, Li H, et al. Pitting corrosion development mechanism of carbon steel in high temperature and high CO_2 partial pressure environment (in Chinese), Corrosion and Protection. 37 (2016) 104-107.

[4] Aslanyan A, Aslanyan I, Arbuzov A, et al. Time-domain Magnetic Defectoscopy For Tubing And Casing Corrosion Detection, SPE 169601-MS. (2014).

DOI: 10.2118/169601-ms

[5] Wang J, Li G, Li B, et al. Damage mechanism and maintenance technology of heavy oil thermal recovery well casing (in Chinese), West Prospecting Engineering. 22 (2010) 96-97.

[6] Chen Y, Xu J, Jia L, et al. Optimization of Tubes under Thermal Stress Intensity Attenuation and High Temperature Corrosion of Sea Thermal Wells (in Chinese), Surface Technology. 47 (2018) 195-201.

[7] Waard. C. D, Lotz U, Milliams. D. E. Predictive Model for CO2 Corrosion engineering in wet natural gas pipelines, Corrosion. 47 (1991) 976-985.

DOI: 10.5006/1.3585212

[8] Eliezer A, Gutman.E.M, Abramov E, et al. Corrosion Fatigue and Mechanochemical Behavior of Magnesium Alloys, Corrosion Reviews. 16 (1998) 1-26.

DOI: 10.1515/corrrev.1998.16.1-2.1

[9] Li H, Bai Z, Li P et al. Study on corrosion influencing factors of API N80 steel in simulated CO2/H2 environment, Proceedings of the 2nd Petrochemical and Petrochemical Industrial Materials Research Conference, Chengdu. (2001) 101-104.

[10] Masamura K, Hashizume S, Sakai J. Polarization behavior of high-alloy OCTG in CO2 environment as Affected by Chlorides and Sulfides, Corrosion. 6 (1987) 359-368.

DOI: 10.5006/1.3583871

[11] Fierro G, Ingo GM, Mancla F. XPS-Investigation on the Corrosion Behavior of 13Cr Martensitic Stainless Steel in CO2-H2S-Cl Environment, Corrosion. 10 (1989) 814-821.

DOI: 10.5006/1.3584988

[12] Sun K, Robello S, Guo B. Effect of Stress Concentration Factors due to Corrosion on Production Tubing Design. Spe Production & Facilities, 20 (2005) 334-339.

DOI: 10.2118/90094-pa

[13] Kampf-Sherf O, Zlotogorski Z, Gilboa A, et al. Analysis on the influence of corrosion on casing strength in acidic gas field development (in Chinese). Oil Drilling & Production Technology, 34 (2012) 114-118.

[14] Wang M, Zhang Z, Zeng D, et al. Experimental study and suggestion on corrosion of casing in high-sulfur gas field (in Chinese). Natural Gas Industry, 31 (2011) 85-87.

[15] Zhang Z, Chen S, Shao M, et al. Effect of corrosion on casing strength in acid gas field development (in Chinese). Oil Drilling & Production Technology, 34 (2012) 114-118.

[16] Zhang Z, Zhang L. Study on thermal stress of free casing in high temperature and high production gas wells (in Chinese). Journal of Safety and Environment, 15 (2015) 98-102.

[17] Lian Z, Luo Z, Yu H, et al. Strength evaluation of casing with corrosion pit defects (in Chinese). Journal of Southwest Petroleum University (Natural Science Edition), 40 (2018) 159-168.

[18] Zhu X, Luo S. Regularized treatment of casing corrosion defects and analysis of crushing strength (in Chinese). Science Technology and Engineering, 17 (2017) 193-198.

[19] Shi X, Chen P, Xu J, et al. Analysis of residual strength of CO_2 pitting corrosion in oil and gas well casings (in Chinese). Natural Gas Industry, 26 (2006) 95-97.

[20] Fan H, Luo J, Li P, et al. Analysis of the influence of corrosion morphology simplification on the residual strength of completion string (in Chinese). Petroleum Machinery, 44 (2016) 65-70.

[21] Xu Z, Yan X, Yang X. Analysis of Dynamic Influence of CO_2 Corrosion on Casing Strength (in Chinese). Journal of Mechanical Engineering, 50 (2014) 169-177.

[22] Gao X, Pan D. Numerical Simulation Analysis of Transient Temperature Field of Thermal Wellbore (in Chinese). Journal of China University of Petroleum, 25 (2001) 67-69.
