Research on Drill Pipe’s Fatigue Life Prediction Based on Reliability

Abstract:

Fatigue life of drill pipe is studied systematically based on reliability analysis. Calculation results show that bending and tensile stress in drill pipe body is significantly greater than that in the tool joint during drilling process. Drill pipe body’s fatigue strength is about 500MPa under the condition that the stress ratio is -1. The fatigue strength of tool joint is about 360MPa under the condition that the average tensile stress is 496MPa. The fatigue fracture position of drill pipe is concentrated on pipe body, and most fatigue cracks originate from pipe’s outer surface. Compared with material fatigue life, the fatigue life of whole drill pipe is significantly lower. Under the condition that the confidence level is 95% and deviation is 5%, drill pipe’s fatigue life distribution is normal distribution while the stress amplitude is 660MPa, 620MPa, 580MPa and 540MPa respectively. With the decreasing of stress amplitude, the peak of logarithmic fatigue life’ probability density distribution curve decreases gradually, and its dispersion increases gradually. Drill pipe’s fatigue life prediction equations whose reliability are 50%, 90%, 99% and 99.9% are calculated separately.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 975-980
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.975
• Online since: January 2019
• Authors: Fang Po Li*
• Keywords: Drill Pipe, Fatigue Life, Fatigue Life Prediction, Reliability

References

[1] LI Fang-po, HAN Li-hong, LIU Yong-gang, et al. Investigation on toughness index of high grade steel drill pipe [J]. Journal of China University of Petroleum, 2011, 35(5): 130-133.

[2] Macdonald K A, Bjune J V. Failure analysis of drill strings[J]. Engineering Failure Analysis, 2007, 30(14): 1641-1666.

DOI: 10.1016/j.engfailanal.2006.11.073

[3] WANG Guangsheng, SHI Kangcai, ZHOU Jingen, etc. Analysis of defects and cases of metal heat treatment [M]. Beijing: Machinery Industry Press, 2007, 100.

[4] Miscow G F, Netto T A. Techniques to characterize fatigue behaviour of full size drill pipes and smallscale samples [J]. International Journal of Fatigue, 2004, 26: 575-584.

DOI: 10.1016/j.ijfatigue.2003.10.014

[5] LI Fangpo, WANG Yong. Review on the Drill Pipe's Fatigue Life Prediction Technology [J]. Material Review, 2015, 29(6): 88-91.

[6] Grondin G. Y, Kulak G Y. Kulak. Fatigue Testing of Drillpipe[J]. Drilling& Completion, 1994, 6: 95-102.

DOI: 10.2118/24224-pa

[7] Angelo Ligrone, Giovanni Botto, Angelo Calderoni. Reliability Methods Applied to Drilling Operation.[R]. SPE29355, (1995).

DOI: 10.2118/29355-ms

[8] SHAO Dong-dong, GUAN Zhi-chuan, WEN Xin, et al. Experiment on lateral vibration characteristics of horizontal rotary drilling string[J]. Journal of China University of Petroleum, 2013, (37)4: 100-103.

[9] WANG Peng, NI Hongjian, WANG Ruihe, et al. Friction reduction research of drill-string longitudinal vibration based on asperity contact[J]. Journal of China University of Petroleum, 2015, 39(1): 88-94.

[10] HAN Lihong, ZHANG Pingsheng. Fitness assessment method for defective drill pipe: SY/T 6719-2008[S]. Beijing: Petroleum Industry Press, (2007).

[11] GAO Zhentong, XIONG Junjiang. Fatigue reliability[M]. Beijing:Beijing University Press of Aeronautics and Astronautics, 2001, 290-293.

[12] CHEN Yukun, ZHAN Jiayu.Manual of Fatigue Test Methods[M]. Beijing: Machinery Industry Press, (1983).
