Synthesis and Characterization of a New Phosphorus-Containing Curing Agent PPDTA

Abstract:

A new phosphorus-containing flame-retardant curing agent PPDTA was synthesized from phenylphosphonic dichloride (PPD) and 3-amino-1,2,4-triazole (TA) in tetrahydrofuran solvent to improve the flame retardancy of epoxy resin. The structure of the compound was analyzed and confirmed by infrared spectroscopy. The effects of reaction time, reaction temperature and ratio of reactants on yield were studied by using three-factor three-level orthogonal experiment. The results show that the yield of PPDTA can reach 86.4%, when the reaction time is 10h, reaction temperature is 70 °Cand the molar ratio of TA to PPD is 2.2:1.

• Periodical: Materials Science Forum (Volume 953)
• Pages: 185-190
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.953.185
• Online since: May 2019
• Authors: Yong Li Peng, Ni An Zhuo*, Can Zhang
• Keywords: 3-Amino-1,2,4-Triazole, Curing Agent, Flame Retardant, Phenylphosphonic Dichloride

References

[1] Xie, C.; Du, J.; Dong, Z.; Sun, S.; Zhao, L.; Dai, L., Improving thermal and flame-retardant properties of epoxy resins by a new imine linkage phosphorous-containing curing agent. Polymer Engineering and Science 2016, 56 (4), 441-447.

DOI: 10.1002/pen.24270

[2] Jiang, P.; Gu, X.; Zhang, S.; Wu, S.; Zhao, Q.; Hu, Z., Synthesis, Characterization, and Utilization of a Novel Phosphorus/Nitrogen-Containing Flame Retardant. Industrial & Engineering Chemistry Research 2015, 54 (11), 2974-2982.

DOI: 10.1021/ie505021d

[3] Liang, B.; Wang, G.; Hong, X.; Long, J.; Tsubaki, N., Synthesis and properties of a new halogen-free flame-retardant epoxy resin curing agent. High Performance Polymers 2016, 28 (1), 110-118.

DOI: 10.1177/0954008315604036

[4] Chen, T.; Chen, X.; Wang, M.; Hou, P.; Jie, C.; Li, J.; Xu, Y.; Zeng, B.; Dai, L., A novel halogen-free co-curing agent with linear multi-aromatic rigid structure as flame-retardant modifier in epoxy resin. Polymers for Advanced Technologies 2018, 29 (1), 603-611.

DOI: 10.1002/pat.4170

[5] Wang, P.; Cai, Z., Highly efficient flame-retardant epoxy resin with a novel DOPO-based triazole compound: Thermal stability, flame retardancy and mechanism. Polymer Degradation And Stability 2017, 137, 138-150.

DOI: 10.1016/j.polymdegradstab.2017.01.014

[6] Xu, M.-J.; Ma, K.; Liu, C.; Li, B., Synthesis of the poly(phosphoric-boric acid) piperazine and its application as an effective flame retardant for epoxy resins. Polymer Engineering And Science 2018, 58 (10), 1858-1867.

DOI: 10.1002/pen.24794

[7] Xu, Y.-J.; Chen, L.; Rao, W.-H.; Qi, M.; Guo, D.-M.; Liao, W.; Wang, Y.-Z., Latent curing epoxy system with excellent thermal stability, flame retardance and dielectric property. Chemical Engineering Journal 2018, 347, 223-232.

DOI: 10.1016/j.cej.2018.04.097

[8] Qian, X.; Song, L.; Hu, Y.; Jiang, S., Novel DOPO-based epoxy curing agents Synthesis and the structure-property relationships of the curing agents on the fire safety of epoxy resins. Journal Of Thermal Analysis And Calorimetry 2016, 126 (3), 1339-1348.

DOI: 10.1007/s10973-016-5604-6

[9] Huo, S.; Wang, J.; Yang, S.; Chen, X.; Zhang, B.; Wu, Q.; Zhang, B., Flame-retardant performance and mechanism of epoxy thermosets modified with a novel reactive flame retardant containing phosphorus, nitrogen, and sulfur. Polymers for Advanced Technologies 2018, 29 (1), 497-506.

DOI: 10.1002/pat.4145

[10] Liu, S.; Fang, Z.; Yan, H.; Wang, H., Superior flame retardancy of epoxy resin by the combined addition of graphene nanosheets and DOPO. Rsc Advances 2016, 6 (7), 5288-5295.

DOI: 10.1039/c5ra25988f

[11] Chen, R.; Gong, J.; Jiang, Y.; Wang, Q.; Xi, Z.; Xie, H., Halogen-free flame retarded cold-mix epoxy asphalt binders: Rheological, thermal and mechanical characterization. Construction And Building Materials 2018, 186, 863-870.

DOI: 10.1016/j.conbuildmat.2018.08.018

[12] Shi, Y.-Q.; Fu, T.; Xu, Y.-J.; Li, D.-F.; Wang, X.-L.; Wang, Y.-Z., Novel phosphorus-containing halogen-free ionic liquid toward fire safety epoxy resin with well-balanced comprehensive performance. Chemical Engineering Journal 2018, 354, 208-219.

DOI: 10.1016/j.cej.2018.08.023

[13] Xu, Z.-Z.; Huang, J.-Q.; Chen, M.-J.; Tan, Y.; Wang, Y.-Z., Flame retardant mechanism of an efficient flame-retardant polymeric synergist with ammonium polyphosphate for polypropylene. Polymer Degradation And Stability 2013, 98 (10), 2011-2020.

DOI: 10.1016/j.polymdegradstab.2013.07.010

[14] Wirasaputra, A.; Yao, X.; Zhu, Y.; Liu, S.; Yuan, Y.; Zhao, J.; Fu, Y., Flame-Retarded Epoxy Resins with a Curing Agent of DOPO-Triazine Based Anhydride. Macromolecular Materials and Engineering 2016, 301 (8), 982-991.

DOI: 10.1002/mame.201600094

[15] Dai, K.; Song, L.; Yuen, R. K. K.; Jiang, S.; Pan, H.; Hu, Y., Enhanced Properties of the Incorporation of a Novel Reactive Phosphorus- and Sulfur-Containing Flame-Retardant Monomer into Unsaturated Polyester Resin. Industrial & Engineering Chemistry Research 2012, 51 (49), 15918-15926.

DOI: 10.1021/ie302106w

[16] Wu, H.; Li, Y.; Zeng, B.; Chen, G.; Wu, Y.; Chen, T.; Dai, L., A high synergistic P/N/Si-containing additive with dandelion-shaped structure deriving from self-assembly for enhancing thermal and flame retardant property of epoxy resins. Reactive & Functional Polymers 2018, 131, 89-99.

DOI: 10.1016/j.reactfunctpolym.2018.07.009
