Observation of Crack Growth Behavior of Various Cracks in 4.762mm Diameter Silicon Nitride Balls under Cyclic Compressive Load

Abstract:

In order to investigate the effect of pre-crack lengths on strength of silicon nitride balls under cyclic pressure loads, growth behavior of 600~700μm pre-cracks were compared to those of 200μm~300μm and 400~500μm pre-cracks. Furthermore, the change in initial threshold limit of the maximum stress intensity factor was discussed. It was found that the increasing ratio of stress intensity factor during N=0 and N=1000 distinguished the failure and non-failure, and pre-crack length had strong effect on the threshold limits of the increasing ratio.

• Periodical: Materials Science Forum (Volume 971)
• Pages: 101-105
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.971.101
• Online since: September 2019
• Authors: Takumi Toriki, Tomoya Matsui, Katsuyuki Kida*
• Keywords: Ball, Fatigue Strength, Silicon Nitride, Stress Intensity Factor, Surface Crack

References

[1] G. Choi, Cyclic fatigue crack growth in silicon nitride: influences of stress ratio and crack closure, Acta metallurgica et materialia. 43, 4(1995)1489-1494.

DOI: 10.1016/0956-7151(94)00356-m

[2] C. J. Gilbert, R. H. Dauskardt, R. O. Ritchie, Microstructural mechanisms of cyclic fatigue-crack propagation in grain-bridging ceramics, Ceramics International. 23,5(1997)413-418.

DOI: 10.1016/s0272-8842(96)00048-x

[3] M. Okazaki, A. J. Mcevily, T. Tanaka, On the mechanism of fatigue crack growth in silicon nitride, Metallurgical Transactions A. 22,6(1991)1425-1434.

DOI: 10.1007/bf02660674

[4] M. Takahashi, N. Okabe, Y. Abe, K. Fujiki, R. Kanbayashi, Fracture analysis for ceramic ball in backflow valve, Fatigue & Fracture of Engineering Materials & Structures. 35,4(2012)291–300.

DOI: 10.1111/j.1460-2695.2011.01619.x

[5] K. Kida, K. Kitamura, H. Chiba, K. Yamakawa, Static and fatigue strengths of pre-cracked silicon nitride balls under pressure load, International Journal of Fatigue. 27(2005)165-175.

DOI: 10.1016/j.ijfatigue.2004.05.010

[6] K. Kida, J. Koga, Edson Costa Santos, Crack growth and splitting failure of silicon nitride ceramic balls under cyclic pressure loads, Mechanics of Materials. 106(2017)58-66.

DOI: 10.1016/j.mechmat.2017.01.004

[7] T. Toriki, T. Matsui, K, Kida, Observation of crack growth behavior of 400µm cracks in 4.762mm silicon nitride balls under cyclic compressive load, proceeding of the 8th ICAMEM(2019).

DOI: 10.4028/www.scientific.net/kem.814.335

[8] Paris. PC, Sih. GC, Stress analysis of cracks. Fracture toughness testing and its application. 381(1965)30–83.

DOI: 10.1520/stp26584s
