Study on a New Kind of Magnetic Abrasive Finishing by Using Alternating Magnetic Field for Ultra-Precision Plane Finishing

Abstract:

In this study, a new plane magnetic abrasive finishing method by using alternating magnetic field has been proposed to solve the problems such as the easy deformation and poorly restored of the magnetic brush in traditional magnetic abrasive finishing. Compared with the magnetic brush in traditional magnetic abrasive finishing, the magnetic brush can keep a relatively stable shape to finish the workpiece under the action of alternating magnetic field. In this paper, the variation of the finishing force in the alternating magnetic field is analyzed theoretically. In addition, in order to get the ultra-precision plane surface, the influence of the size of the magnetic particles, the size of the GC particles, and the frequency of the AC power on the finishing characteristics has been studied. The best experimental results show that the surface roughness of the workpiece is improved from 38 nm Ra to 6.33 nm Ra.

• Periodical: Materials Science Forum (Volume 977)
• Pages: 42-49
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.977.42
• Online since: February 2020
• Authors: Chao Wen Dong, Yan Hua Zou*, Hui Jun Xie
• Keywords: Alternating Current, Magnetic Abrasive Finishing, Ultra-Precision Finishing

References

[1] T. Shinmura, K. Takazawa, E. Hatano, Study on magnetic abrasive process –aplication to plane finishing, Bull. Jpn. Soc Precis. Eng. 19(4) (1985) 289-294.

[2] T. Shinmura, K. Takazawa, Study on magnetic abrasive finishing – characteristics of finished surface, Bull. Jpn. Soc Precis. Eng. 53 (11) (1987) 1791-1793.

[3] Yanhua Zou, Anyuan Jiao, Toshio Aizawa, , Study on Plane Magnetic Abrasive Finishing Process- Experimental and Theoretical Analysis on Polishing Trajectory, Advanced Materials Research 126-128 (2010) 1023-1028.

DOI: 10.4028/www.scientific.net/amr.126-128.1023

[4] Yanhua Zou, T. Shimura, Mechanism of a Magneticd Field Assited Finishing Process Using a Magnetic Tool and Magnetic Particles, Key Engineering Materials 339 (2007) 106-113.

DOI: 10.4028/www.scientific.net/kem.339.106

[5] A.Y. Jiao, H.J. Quan, Z.Z. Li, Y.H. Zou, Study on Improving the Trajectory to Elevate the Surface Quality of Plane Magnetic Abrasive Finishing, Int. J. Adv. Manuf. Technol. 80 (9–12) (2015) 1613–1623.

DOI: 10.1007/s00170-015-7136-9

[6] Singh DK, Jain VK, Raghuram V, Komanduri R Analysis of surface texture generated by a flexible magnetic abrasive brush, Wear 259(7) (2005) 1254-1261.

DOI: 10.1016/j.wear.2005.02.030

[7] Singh L, Khangura SS, Mishra PS, Performance of abrasive used in magnetically assisted finishing: a state of the art review, Int. J. Adv. Manuf. Technol. 3 (2010) 215-227.

DOI: 10.1504/ijat.2010.034052

[8] Yanhua Zou, Huijun Xie, Chaowen Dong, Jinzhong Wu, Study on complex micro surface finishing of alumina ceramic by the magnetic abrasive finishing process using alternating magnetic field, Int. J. Adv. Manuf. Technol. 97 (2018) 2193–2202.

DOI: 10.1007/s00170-018-2064-0

[9] Huijun Xie, Yanhua Zou, Chaowen Dong, Jinzhong Wu, Study on the magnetic abrasive finishing process using alternating magnetic field: investigation of mechanism and applied to aluminum alloy plate, Int. J. Adv. Manuf. Technol. 102 (2019) 1509–1520.

DOI: 10.1007/s00170-018-03268-8

[10] Jiang Guo, HENRY JIA HUA JONG, Novel localized vibration-assisted magnetic abrasive polishing method using loose abrasives for V-groove and Fresnel optics, Optics Express 26 (2018) 11608-11619.

DOI: 10.1364/oe.26.011608

[11] Jiang Guo, Chun Wai Kum, New vibration-assisted magnetic abrasive polishing (VAMAP) method for microstructured surface finishing, Optics Express, 24/12 (2016) 13542-13554.

DOI: 10.1364/oe.24.013542
