Sealing Performance and Mechanism of a High-Temperature Near-Neutral Sealing Adhesive in the Ternary System of ZrO₂-Al₂O₃-SiO₂

Abstract:

A high-temperature sealing adhesive was prepared using kyanite, andalusite, and magnesia fully stabilized zirconia (Mg-FSZ) as raw materials and nanozirconia (ZrO₂) sol as binder. The adhesive is chemically near-neutral and suitable for bonding acid, neutral, or alkaline materials at 1560 °C. The mineral composition, volume expansion, and air permeability of multiple thermal cycles were analyzed. Results showed that the volume expansion caused by the mullitization of kyanite and andalusite can compensate for the sintering shrinkage high temperature. MgO could gradually desolvatize from the Mg-FSZ particles and react with SiO₂ and Al₂O₃ to produce a stable forsterite and magnesium aluminate spinel. Hence, Mg-FSZ became unstable, and cubic ZrO₂ transformed into monoclinic ZrO₂ when cooled, leading to a volume expansion of the adhesive, which ensured the sealing effect. A larger critical particle size of Mg-FSZ can provide the adhesive with a more persistent volume expansion during thermal cycles due to the more durable desolvatization of MgO. The nanoZrO₂ sol binder can improve the sintering of the adhesive and bonding of the joint, resulting in a low gas permeability.

• Periodical: Materials Science Forum (Volume 977)
• Pages: 65-71
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.977.65
• Online since: February 2020
• Authors: Li Biao Xiao, Dian Zhang*, Yi Jun Liu, Li Min Pan, Qun Hu Xue
• Keywords: High-Temperature Adhesive, Magnesia Fully Stabilized Zirconia, Phase Transformation, Sealing Performance

References

[1] B. Tinnes, Zollikerberg and Switzerland, Sealing means for the joint of a casting ladle closure, US, Patent, 4076154, 2, 28(1978).

[2] A. J. Klimas, Method and apparatus for testing the integrity of a shrould seal on a ladle for a continuous casting installation. US, Patent, 7628952 B2, 12, 8(2009).

[3] J. C. Daussan, G. Daussan and A. Daussan, Pasty gasket for producing a leakproof seal between surfaces which are subjected to heat and which have to be joined. US, Patent, 4939033, 7, 3(1990).

[4] T. Nishio and T. Katayose, Filler material for filling an outlet aperture of a casting ladle or similar container and a process for producing the filler materials, US, Patent, 4667858, 5, 26(1987).

[5] T. Shigeaki, N. Noriyoshi and E. Andy, Stopper for continuous casting, US, Patent, 6478201 B2, 11, 12(2002).

[6] Q. L. Zhang. Development and application of micro-expansion high-aluminum fire mud, WISCO Technol. 6(1998) 6-7.

[7] B. Wei, Low expansion silicon castable, Refractories & Lime. 39(2014) 29-30.

[8] X. L. Tian, Q. H. Xue and C. B. Xue, Alumina-zirconia composite powder prepared by sol-gel process, J. Chin. Ceram. Soc. 40(2012) 866-871.

[9] Q. H. Xue and W. Z. Xu, Refractory (in Chinese), Metallurgical Industry Press, Beijing, 2009, p.18.

[10] Q. H. Xue, Y. H. Zhou and B. K. Liu, Effect of composite stabilizer on phase composition and properties of ZrO2 metering nozzle. J. Chin. Ceram. Soc. 43(2015) 1806-1812.

[11] S. C. Farmer, A. H. Heuer and R. H. J. Hannink, Eutectoid Decomposition of MgO-Partially-Stabilized ZrO2. J. Am. Ceram. Soc. 70(1987) 431-440.

DOI: 10.1111/j.1151-2916.1987.tb05664.x

[12] S. Serena, M. A. Sainz, S. De. Aza, et al., Thermodynamic assessment of the system ZrO2-CaO-MgO using new experimental results calculation of the isoplethal section CaO-MgO-ZrO2. J. Eur. Cera. Soc. 25(2005) 681-693.

DOI: 10.1016/s0955-2219(04)00077-9

[13] C. Ribeiro, M. D. M. Innocentini and V. C. Pandolfelli, Dynamic permeability behavior during drying of refractory castables based on calcium free alumina binders, J. Am. Ceram. Soc. 84(2001) 248-250.

DOI: 10.1111/j.1151-2916.2001.tb00644.x

[14] J. F. Shackelford and R. H. Doremus, Ceramic and Glass Materials, Structure, Properties and Processing. Springer Science, USA, New York, 2008, pp: 41-48.

[15] L. Zhao, Q. H. Xue and D. H. Ding, Effects of the precipitation of stabilizers on the mechannism of grain fracturing in a zirconia metering nozzle, Int. J. Min. Met. Mater. 23(2016) 1041-1047.

DOI: 10.1007/s12613-016-1321-1
