Casing Bearing Capacity with Shear Load for Shale Gas Wells

Abstract:

Casing radial deformation during complex fracturing process was seriously for shale gas wells in Sichuan district of China, and the average casing deformation rate in the region is of 50%. The bridge plug, perforating gun and other tools cannot successfully pass with deformed casing. Aiming at the 3-D logging morphology for deformed casing of shale gas wells, the failure modes and mechanisms were analyzed by using elasticity and theoretical mechanics. Many factors were evaluated and integrated to achieve quantitative evaluation model including geology feature, wellbore trajectory, cement property, casing material and hydrofracture process. With the aid of the self-developed unconventional oil and gas well casing simulation test equipment, the casing bearing capacity with shear load were carried out, established the relationship between shear load value and radial deformation, and further constructed the casing failure criterion with shear force. This work can provide technical support for casing design and selection in shale gas wells.

• Periodical: Materials Science Forum (Volume 993)
• Pages: 1190-1195
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.993.1190
• Online since: May 2020
• Authors: Shang Yu Yang*, Jian Jun Wang, Jia Wen Han, Hang Wang, Li Hong Han
• Keywords: Bearing Capacity, Casing Deformation, Shale Gas, Shear Load

References

[1] Zou Caineng, Yang Zhi, He Dongbo, et al. Theory, technology and prospects of conventional and unconventional natural gas. Petroleum Exploration and Development, 45(4) (2018)575-587.

[2] Guoxusheng, Liyuping, Liu Ruobing, et al. Characteristics and controlling factors of micro pore structures of longmaxi shale play in the jiaoshiba area, Sichuan basin. Natural gas industry, 34(6):9-16 (2014).

DOI: 10.1016/j.ngib.2014.11.007

[3] ISO/TR 10400, Petroleum and natural gas industries-equations and calculations for the properties of casing, tubing, drill pipe and line pipe used as casing and tubing (2007).

DOI: 10.3403/30175233u

[4] API SPEC 5CT.Specification for casing and tubing,10thedition. washington, DC:API (2018).

[5] Cui yueming. Mechanism of formation slippage and shear casing damage of the marker bed in sazhong development area of daqingoilfield. PhD thesis, Northeast petroleum university (2015).

[6] Wang suling, Yanglei. Numerical simulation and influencing factors analysis on casing shear damage in shale layer. China petroleum machinery, 46(1) (2018).100- 105.

[7] Hong guobing, Chen mian, Lu yunhu et al. Study on the anisotropy characteristics of deep shale in the southern Sichuan basin and their impacts on fracturing pressure. Petroleum drilling techniques, 46(3) (2017)78-85.

[8] Xie jueren. A study of strain based design criteria for thermal well casings, world heavy oil conference, Edmonton, Canada, 388 (2008).

[9] IRP, Industry recommended practices for heavy oil and oil sand operations, 3(2002).

[10] GB/T 34907-2017. Technical specifications and fitness for service evaluation method for thermal well casing under cyclic steam simulation process (2017).

[11] Han lihong, Wang hang, Wang jianjun, et al. Strain based casing design for cyclic steam simulation wells. SPE Production & operations, SPE180703 (2018).

DOI: 10.2118/180703-pa
