Dielectric, Magnetic and Magnetoelectric Properties of a Laminated Composite with 1-3 Connection

Abstract:

A two-phase laminated composite was prepared by stacking one layer of thicknesspolarized 1−3 piezoelectric composite (PECP) plate between two layers of length-magnetized 1−3 magnetostrictive composite (MSCP) plates in the thickness direction. The PECP plate consisted of 0.68 volume-fraction PZT bars embedded in Spurr epoxy matrix, while the MSCP plates comprised 0.51 volume-fraction Terfenol-D particles embedded and magnetically aligned in Spurr epoxy matrix. The dielectric, magnetic and magnetoelectric properties of the laminate were measured as a function of both frequency and magnetic bias field. A giant magnetoelectric voltage coefficient ( αE) of 15.4 V/cm·Oe was observed at the resonance frequency of ~59 kHz under a relatively low bias field of 0.75 kOe. This resonance αE was ~30 times larger than its non-resonance values, showing promising application of the proposed laminate in magnetoelectric conversion devices.

• Periodical: Solid State Phenomena (Volume 111)
• Pages: 147-150
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.111.147
• Online since: April 2006
• Authors: S.W. Or, N. Cai
• Keywords: Magnetoelectric Composites, Magnetostrictive Composites, Piezoelectric Composite

References

[1] P. Curie: J. de Physique 3e ser (1894), p.393.

[2] V.J. Folen, G.T. Rado and E.W. Stalder: Phys. Rev. Lett. Vol. 6 (1961), p.607.

[3] G.R. Harshe: PhD Thesis (The Pennsylvania State University, USA 1991).

[4] K. Mori: PhD Thesis (University of Maryland, College Park, USA 2002).

[5] S. Dong, J.F. Li and D. Viehland: Appl. Phys. Lett. Vol. 83 (2003), p.2265.

[6] S.W. Or, N. Nersessian and G.P. Carman: IEEE T. Magn. Vol. 40 (2004), p.71.

[7] S.W. Or, T. Li and H.L.W. Chan: J. Appl. Phys. Vol. 97 (2005), p. 10M308-1.

[8] S.W. Or and H.L.W. Chan: J. Appl. Phys. Vol. 90 (2001), p.4122.
