Design of Sensor System for the Linear Actuator of Stewart Platform

Abstract:

The article deals with description of design of sensor system for linear actuators. These constitute a part of a parallel kinematic machine based on a structure of a Stewart platform. The machine is intended for testing of bone implants in biomechanical and medical practice. The developed Stewart platform presents a mechatronic system. Hence the design of mechatronic systems known as a V-model was used. The system of sensors has been developed since the middle phase of the Stewart platform development.

• Periodical: Solid State Phenomena (Volume 164)
• Pages: 15-18
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.164.15
• Online since: June 2010
• Authors: Pavel Houška, Tomáš Březina
• Keywords: Absolute Position Sensor, Force Measurement, Sensor, Stewart Platform, Strain Gage

References

[1] T. Březina: Simulation modelling of mechatronic systems II, Brno University of Technology, Faculty of Mechanical Engineering, Brno (2006).

[2] T. Březina: Simulation modelling of mechatronic systems III, Brno University of Technology, Faculty of Mechanical Engineering, Brno (2007).

[3] K. Hoffman: An Introduction to Measurement using Strain Gages, Hottinger Baldwin Messtechnik GmbH, Dramstadt (1989).

[4] VDI 2206: Design methodology for mechatronic systems. Berlin: Beuth Verlag (2004).
