Application of Non-Linear Correction Systems for Control of Work Movements of the Mobile Crane under a Threat of Stability Loss

Abstract:

A payload displacement in mobile cranes is performed via an adequate composition of working movements. Hoists are used for lifting and lowering of a payload. The following devices are used for displacement of a payload from initial point to another one: a mechanism for generation of crane slewing motion and a mechanism of reach variation. Displacement of heavy payloads by mobile cranes in some conditions can lead to a loss of stability. In this paper authors propose assessment of a stability surplus via: monitoring of values of stress forces of the supports on the ground, calculation of the vertical resultant force of these stress forces and determination of the acting point of the resultant force. The mathematical model of the control system (regulating chassis slewing motion) integrated in the intervention system of a jib reach is presented. Finally, some representative results of numerical simulations are provided.

• Periodical: Solid State Phenomena (Volume 164)
• Pages: 25-30
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.164.25
• Online since: June 2010
• Authors: Jarosław Janusz, Jacek Kłosiński
• Keywords: Control System, Mobile Crane, Stability

References

[1] Janusz J.: Analiza dynamiczna układu sterowania ruchami roboczymi żurawia w warunkach zagrożenia utraty stateczności, Rozprawa doktorska. Bielsko-Biała: Akademia TechnicznoHumanistyczna Wydział Budowy Maszyn i Informatyki, 18. 11 (2005).

DOI: 10.53052/9788366249837.35

[2] Kłosiński J., Janusz J.: Sterowanie ruchami roboczymi żurawia samochodowego ograniczające zagrożenie utraty jego stateczności. W: Systemy ograniczające zagrożenia w procesach eksploatacji maszyn i urządzeń. Zakopane 15-17. 11. 2005, T. 2. - Gliwice: Komdruk-Komag Sp. z o. o., (2005).

[3] Kłosiński J., Janusz J., Sidzina M.: Badania symulacyjne układu zapobiegania utracie stateczności żurawia samochodowego z wykorzystaniem regulatora FLC. Transport Przemysłowy Nr 4(18) (2004), pp.36-39 (in Polish).

[4] Kłosiński J., Janusz J.: Control of Operational Motions of a Mobile Crane under a Threat of Loss of Stability. Solid State Phenomena Vol. 144 (2009) pp.77-82.

DOI: 10.4028/www.scientific.net/ssp.144.77

[5] K. Takagi, H. Nishimura: Control of a jib-type crane mounted on a flexible structure. Control Systems Technology, IEEE Transactions on Vol. 11, Issue 1, Jan. (2003), pp.32-42.

DOI: 10.1109/tcst.2002.806435

[6] KŁOSIŃSKI J.: Controlling of work motions of mobile cranes assuring positioning of the payload. ZN, Budowa i eksploatacja Maszyn, Rozprawy Naukowe nr 55, Bielsko-Biała (2000) (in Polish).
