Technological Features Influence on Magnetic Sensitivity of Ferromagnetic Structures

Abstract:

The main urgent problems of the magnetic devices and primary conventers development based on the magnetoresistive structures are the sensitivity improvement and thermal stability. This paper discusses how to use the magnetoresistive structures based on nanoscale films of permalloy Ni (80%) Fe (20%) in the sensory systems. It is shown the variation of the shape and size ratio of magnetoresistive elements influences the characteristics of the magnetization and the dynamic range of the sensors, as well as maximum magnetic field sensitivity. The optimization of magnetoresistive structures topological sizes was carried out and sensor design with the highest sensitivity was chosen. It is shown that sensitivity of sensors can achieve value of 20.7 (mV/V)/(kA/m) by changing bias field. The ability to function in a large temperature range with coefficient of thermal stability - 0.35 %/°С was demonstrated for the obtained magnetoresistive structures.

You might also be interested in these eBooks

Physics and Technology of Nanostructured Materials III (Supplement Book)

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 247)

Pages:

124-130

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.247.124

Citation:

Cite this paper

Online since:

March 2016

Authors:

Vladimir A. Bespalov, Nikolay A. Djuzhev, Aleksey Iurov, Nikita Mazurkin, Maksim Chinenkov*, Roman Preobrazhensky

Keywords:

Magnetoresistance, Magnetoresistive Sensor, Magnetoresistor, MEMS

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] U. Dibbern, Magnetoresistive Sensors, in: W. Gopel, J. Hesse, J. N. Zemel, Sensors vol. 5, Copyright VCH Verlagsgesellschaft mbH, Hannover, 1989, p.341 – 380.

Google Scholar

[2] S. Tumanski. Thin film magnetorsistive sensors (2001).

Google Scholar

[3] A.P. Boltaev, F.A. Pudonin, and I.A. Sherstnev, Interplay of electron correlations and localization in disordered β-tantalum films: Evidence from dc transport and spectroscopic ellipsometry study, Applied Physics Letters 14 (2013) 142-144.

DOI: 10.1063/1.4907862

Google Scholar

[4] M. Yu. Chinenkov, N.A. Dyuzhev, V.A. Bespalov, A.S. Yurov, A.F. Popkov, A.A. Kovalev, N.S. Mazurkin, Sensor application features of magnetoresistive nanoscale structures, Conference proceedings Nanocon 2012, 23 (2012) 89.

Google Scholar

[5] W. Kwiatkowski, W., Tumanski, The permalloy magnetoresisitve sensors – properties and applications, Phys. E (1986) 502-515.

Google Scholar

[6] H. Hoffmann, Magnetic properties of thin ferromagnetic films in relation to their structure, Thin Solid Films 58 (1979) 223-233.

DOI: 10.1016/0040-6090(79)90241-4

Google Scholar

[7] K. Asama, K. Takahashi, M. Hirano: submitted to AIP Con. Proc. (1973).

Google Scholar

[8] N.A. Djuzhev, N.S. Mazurkin, V.S. Pozdnyakov, A.S. Iurov, M. Yu. Chinenkov. Magnetic-field sensors based on anisotropic magnetoresistive thin-film structures for operation in a wide temperature range, Semiconductors, 49, 13 (2015) 1739-1742.

DOI: 10.1134/s1063782615130060

Google Scholar
