Study of Flow-Induced Vibration Phenomena in Automotive Shock Absorbers

Abstract:

The purpose of this study was to develop a model of the dynamic behavior of a hydraulic vehicle double-tube shock absorber. The model accounts for the effects of compressibility, valve stiction, inertia, etc. and can be suitable for use in the analyses on flow-induced pressure fluctuations in the device. The author highlights all major variables to influence the output of the shock absorber, and then proceeds by performing a series of simulations using the developed model. The model is demonstrated to operate well in the large amplitude and low frequency range as well as the small amplitude and high frequency excitation operation regimes. The results are presented in the form of time histories of pressures in each fluid volume of the damper, flow rates through the valves, piston rod acceleration and force. Fast Fourier Transform (FFT) graphs are presented, too, in order to identify major components of the pressure fluctuation phenomena in frequency domain.

• Periodical: Solid State Phenomena (Volume 248)
• Pages: 204-210
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.248.204
• Online since: March 2016
• Authors: Marian Sikora*
• Keywords: Automotive, Double-Tube Shock Absorber, Lumped Parameter Model, Vibration

References

[1] J. C. Dixon, The shock absorber handbook, Professional Engineering Publishing Ltd and John Wiley and Sons, Ltd, (2007).

[2] H. H. Lang, A study of the characteristics of automotive hydraulic dampers at high stroking frequencies, The University of Michigan, (1977).

[3] P. Czop, D. Sławik, P. Śliwa, G. Wszołek, Simplified and advanced models of a valve system used in shock absorbers, Journal of Achievements in Materials and Manufacturing Engineering 33(2) (2009) 173-180.

[4] A. Farjoud, M. Ahmadian, M. Craft, ·W. Burke, Nonlinear modeling and experimental characterization of hydraulic dampers: effects of shim stack and orifice parameters on damper performance, Nonlinear Dynamics 67 (2012) 1437-1456.

DOI: 10.1007/s11071-011-0079-2

[5] S. Duym , R. Steins, K. Reybrouck, Evaluation of shock absorber models, Vehicle System Dynamics: International Journal of Vehicle Mechanics and Mobility 27(2) (1997) 109-127.

DOI: 10.1080/00423119708969325

[6] A. Kruse, Analysis of dynamic pressure build-up in twin-tube vehicle shock absorbers with respect to vehicle acoustics, SAE International, Vehicle Dynamics Expo 2008, Stuttgart, (2008).

[7] A. Kruse, Characterizing and reducing structural noises of vehicle shock absorber system, SAE Technical Report 2002-01-1234 (2002).

DOI: 10.4271/2002-01-1234

[8] H. Ezzat Khalifa, Xin Liu, Analysis of stiction effect on the dynamics of compressor suction valve, The International Compressor Engineering Conference, (1998).
