Microstructure and Tempering Behaviour of 28Cr-2.5C-1W Cast Irons

Abstract:

In this work, the effects of 1 wt.% tungsten addition and variation in tempering times on the microstructure and hardness of nominal 28 wt.%Cr high chromium irons were investigated. As-cast samples were destabilised at 1050 °C for 4 hours and then hardened by air cooling. Tempering after destabilisation was carried out at 450 °C for 2, 4 and 6 hours followed by air cooling. X-ray diffractometry, light microscopy and scanning electron microscopy were used to characterize the microstructures of the irons. The results show that the as-cast microstructure of the iron without W addition consisted of primary austenite dendrites with eutectic M₇C₃ and eutectic austenite partially transformed to martensite. The iron with 1 wt.%W addition contained primary M₇C₃ and eutectic M₇C₃ in an austenite matrix. Destabilisation treatment of the austenite matrix in both irons allowed precipitation of secondary carbides and transformation to martensite during air cooling. Phase transformation of eutectic M₇C₃ was also found in the iron with W addition. The formation of primary M₇C₃ in the 1 wt.%W iron increased the as-cast macro-hardness from 500 (no W) to 576 HV₃₀. Destabilisation increased the macro-hardness up to 736 (no W) and 780 HV₃₀ (1 wt.%W) since secondary carbide precipitation allowed austenite to transform to essentially martensitic matrices. At longer tempering times, the macro-hardness further increased up to about 820 HV₃₀.

• Periodical: Solid State Phenomena (Volume 283)
• Pages: 116-123
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.283.116
• Online since: September 2018
• Authors: Sasitorn Yeekew, Amporn Wiengmoon*, Torranin Chairuangsri, John T.H. Pearce
• Keywords: Heat Treatment, High Chromium Iron, Microstructure, Tungsten

References

[1] J.T.H. Pearce, High chromium cast irons to resist abrasive wear, Foundryman. 95 (2002) 156-166.

[2] C.P. Tabrett, I.R. Sare, M. R. Ghomashchi, Microstructure-property relationships in high chromium white iron alloys, Int. Mater. Rev. 41 (1996) 59-82.

DOI: 10.1179/imr.1996.41.2.59

[3] F. Maratray, A. Poulalion, Austenite retention in high chromium white irons, AFS Trans. 90 (1982) 82-87.

[4] S.H.M. Anijdan, A. Bahrami, N. Varahram, P. Davami, Effects of tungsten on erosion-corrosion behavior of high chromium white cast iron, Mater. Sci. Eng. A. 454-455 (2007) 623-628.

DOI: 10.1016/j.msea.2006.11.128

[5] Y. Lv, Y. Sun, J. Zhao, G. Yu, J. Shen, S. Hu, Effect of tungsten on microstructure and properties of high chromium cast iron, Mater. Des. 39 (2012) 303-308.

DOI: 10.1016/j.matdes.2012.02.048

[6] E. Carrillo, A. Bedolla, I. Mejia, C.M. Zepeda, J. Zuno, Effects of tungsten on the microstructure and on the abrasive wear behavior of a high-chromium white iron, Wear. 376-377 (2017) 77-85.

DOI: 10.1016/j.wear.2017.02.043

[7] S. Imurai, C. Thanachayanont, J.T.H. Pearce, K. Tsuda, T. Chairuangsri, Effects of W on microstructure of as-cast 28 wt.%Cr-2.6 wt.%C- (0-10) wt.%W irons, Mater. Charact. 99 (2015) 52-60.

DOI: 10.1016/j.matchar.2014.11.012

[8] A. Wiengmoon, T. Chairuangsri, N. Poolthong, J.T.H. Pearce, Electron microscopy and hardness study of a semi-solid processed 27 wt%Cr cast iron, Mater. Sci. Eng. A. 480 (2008) 333-341.

DOI: 10.1016/j.msea.2007.07.043

[9] A. Wiengmoon, T. Chairuangsri, A. Brown, R. Brydson, D.V. Edmonds, J.T.H. Pearce, Microstructural and crystallographical study of carbides in 30wt.%Cr cast irons, Acta Mater. 53 (2005) 4143-4154.

DOI: 10.1016/j.actamat.2005.05.019

[10] A. Wiengmoon, T. Chairuangsri, J.T.H. Pearce, Microstructural Study of Destabilised 30 wt%Cr–2.3 wt%C High Chromium Cast Iron, ISIJ Inter. 44 (2004) 396-403.

DOI: 10.2355/isijinternational.44.396
