Coaxial Aperture Arrays Produced by Ultrafast Direct Femtosecond Laser Processing with Spatially Multiplexed Cylindrical Vector Beams

Abstract:

Direct femtosecond laser printing was used to fabricate circular-and coaxial-shaped hole arrays at ultrafast printing rate up to 10⁶ elements per second. To achieve such fast printing rate, we implemented a spatial multiplexing of either a single Gaussian or cylindrical vector beams into linear array of identical laser spots. Being compared to ordinary microholes, the coaxial openings arranged at the same periodicity demonstrate enhanced transmission in the mid-IR spectral range resulted from coupling between localized electromagnetic mode supported by coaxial unit cell and the lattice-type surface plasmon resonance. At optimized geometry of the coaxial openings and their arrangement we demonstrated resonant transmission as high as 92% at wavelengths ranging from 7.5 to 9 μm. This makes the coaxial microhole arrays with tailored spectral properties produced with ultrafast and inexpensive direct laser printing promising for sensing applications based on surface enhanced infrared absorption.

• Periodical: Solid State Phenomena (Volume 312)
• Pages: 148-153
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.312.148
• Online since: November 2020
• Authors: Dmitrii V. Pavlov*, Aleksey P. Porfirev, Anton Dyshliuk, Aleksandr A. Kuchmizhak
• Keywords: Coaxial Apertures, Donut-Shaped Beams, FTIR Spectroscopy, Hole Arrays, Laser Processing, Lattice Resonances, Spatial Beam Multiplexing, Thin Gold Films

References

[1] T.W. Ebbesen, H.J. Lezec, H.F. Ghaemi, T. Thio and P.A. Wolff, Extraordinary optical transmission through sub-wavelength hole arrays, Nature, 391 (1998) 667-669.

DOI: 10.1038/35570

[2] W. Fan, S. Zhang, B. Minhas, K.J. Malloy, S.R.J. Brueck, Enhanced Infrared Transmission through Subwavelength Coaxial Metallic Arrays, Phys. Rev. Lett. 94 (2005) 033902.

DOI: 10.1103/physrevlett.94.033902

[3] Y. Poujet, J. Salvi and F.I. Baida, 90% Extraordinary optical transmission in the visible range through annular aperture metallic arrays, Opt. Lett. 32 (2007) 2942-2944.

DOI: 10.1364/ol.32.002942

[4] L. Lin and A. Roberts, Angle-robust resonances in cross-shaped aperture arrays, Appl. Phys. Lett. 97 (2010) 061109.

DOI: 10.1063/1.3481068

[5] J.W. Lee, M.A. Seo, D.S. Kim, J.H. Kang and Q.H. Park, Polarization dependent transmission through asymmetric C-shaped holes, Appl. Phys. Lett. 94 (2009) 081102.

DOI: 10.1063/1.3088851

[6] K.K. Koerkamp, S. Enoch, F.B. Segerink, N.F. Van Hulst and L. Kuipers, Strong influence of hole shape on extraordinary transmission through periodic arrays of subwavelength holes, Phys. Rev. Lett. 92 (2004) 183901.

DOI: 10.1103/physrevlett.92.183901

[7] R.W. Gerchberg and W.O. Saxton, A practical algorithm for the determination of the phase from image and diffraction plane pictures, Optik, 35 (1972) 237-246.

[8] D. Pavlov, S. Gurbatov, S.I. Kudryashov, P.A. Danilov, A.P. Porfirev, S.N. Khonina, O.B. Vitrik, S.A. Kulinich, M. Lapine, and A.A. Kuchmizhak, 10-million-elements-per-second printing of infrared-resonant plasmonic arrays by multiplexed laser pulses, Opt. Lett. 44 (2019) 283-286.

DOI: 10.1364/ol.44.000283

[9] S.I. Kudryashov, P.A. Danilov, A.P. Porfirev, I.N. Saraeva, T.H.T. Nguyen, A.A. Rudenko, R.A. Khmelnitskii, D.A. Zayarny, A.A. Ionin, A.A. Kuchmizhak, S.N. Khonina, O.B. Vitrik, High-throughput micropatterning of plasmonic surfaces by multiplexed femtosecond laser pulses for advanced IR-sensing applications, Appl. Surf. Sci. 484 (2019) 948-956.

DOI: 10.1016/j.apsusc.2019.04.048

[10] M. Beresna, M. Gecevicius, P.G. Kazansky and T. Gertus, Radially polarized optical vortex converter created by femtosecond laser nanostructuring of glass, Appl. Phys. Lett. 98 (2011) 201101.

DOI: 10.1063/1.3590716

[11] A. Porfirev, S. Khonina, Y. Azizian-Kalandaragh, M. Kirilenko, Efficient generation of arrays of closed-packed high-quality light rings, Photonics Nanostruct. 37 (2019) 100736.

DOI: 10.1016/j.photonics.2019.100736

[12] F.I. Baida, D. Van Labeke, G. Granet, A. Moreau and A. Belkhir, Origin of the super-enhanced light transmission through a 2-D metallic annular aperture array: a study of photonic bands, Appl. Phys. B 79 (2004) 1-8.

DOI: 10.1007/s00340-004-1497-3
