The Residual Stress Modeling in Surface Plastic Deformation Machining Processes with the Metal Hardening Effect Consideration

Abstract:

The metal workpiece Surface Layer (SL) Residual Stresses (RS) modeling and computational algorithms creation relevance is shown. The RS forming discrete elastoplastic finite element model at Surface Plastic Deformation (SPD) hardening treatment, including technological inheritance effect, is presented. A model feature is the complex non-monotonic types of metal loading and subsequent unloading and hardened body effect consideration, as well as residual stress tensor components evaluation as a result of these effects. Residual stress tensor components calculations in the workpiece hardened surface layer after treatment with different routines are performed. The metal hardening effect on the residual stresses values and distribution is established. The correlations between the residual stress tensor components and the main treatment routine parameters - the roller tension and profile radius are established.

• Periodical: Solid State Phenomena (Volume 328)
• Pages: 27-37
• DOI: https://doi.org/10.4028/p-z92o0e
• Online since: February 2022
• Authors: Maxim S. Makhalov, V.Yu. Blumenstein
• Keywords: Deformation Zone, Hardening, Plastic Flow, Plasticity Reserve, Residual Stresses, Stress-Strain Condition, Surface Layer, Surface Plastic Deformation, Technological Inheritance
