Dynamic Elastic Properties of E-Glass Randomly Oriented Fiber Reinforced SR GreenPoxy Composite - Experimental and Numerical Analysis

Abstract:

In this article, the in-plane dynamic elastic properties of an E-glass randomly oriented fiber-reinforced SR GreenPoxy 56 composite were obtained based on the procedure specified in the ASTM E1876-21 standard. The experimental frequencies and the ones predicted by the simulation of the experimental procedure using a finite element analysis developed in the Patran/Nastran 2021 package were used in an iterative algorithm using sensitivity analysis to improve the first approaches of the dynamic elastic properties obtained by the impulse excitation technique. These experimental results are compared with the ones obtained by the 2D Short Fiber Composite model of the E-glass randomly oriented fiber-reinforced SR GreenPoxy 56 composite, developed in the Patran/Nastran 2021 software.

• Periodical: Solid State Phenomena (Volume 372)
• Pages: 77-84
• DOI: https://doi.org/10.4028/p-1FIt4W
• Online since: July 2025
• Authors: Armando Ramalho*, Marcelo Gaspar, Mário Correia, Joel Vasco, Carlos Capela, Rui B. Ruben
• Keywords: E-Glass Fibers, GreenPoxy Composite, Halpin-Tsay Model, Impulse Excitation/Resonant Technique, In-Plane Dynamic Elastic Properties

References

[1] P. Chaupal and D. Kumar, "Progressive Damage Analysis of Random Oriented Chopped Glass Fiber-Reinforced Laminate Under Three-Point Bending Test," Journal of The Institution of Engineers (India): Series D, vol. 104, no. 2, p.753–766, Dec. 2023.

DOI: 10.1007/s40033-022-00410-5

[2] O. A. Z. Errajhi, J. R. F. Osborne, M. O. W. Richardson, and H. N. Dhakal, "Water absorption characteristics of aluminised E-glass fibre reinforced unsaturated polyester composites," Compos Struct, vol. 71, no. 3–4, p.333–336, Dec. 2005.

DOI: 10.1016/j.compstruct.2005.09.008

[3] G. dos Santos Silva, C. Capela, and M. Gaspar, "Developing Sustainable Materials for Marine Environments: Algae as Natural Fibers on Polymer Composites," Lecture Notes in Mechanical Engineering, p.198–205, 2020, [Online]. Available:

DOI: 10.1007/978-3-030-29041-2_25

[4] E. Mohamed, M. Mubarak, R. Hamid, M. Al-Kalali, A. Husein, and B. Sami Mahdi, "Mechanical Properties of Chopped E-Glass Fiber Reinforced Epoxy Resin," Journal of Mechanical Engineering Research and Developments, vol. 43, no. 2, p.247–256, 2020.

[5] A. Ramalho, D. Freitas, and H. Almeida, "Evaluation of the structural strength of anisotropic PLA components manufactured by 3D printing," Procedia Structural Integrity, vol. 53, p.81–88, 2024.

DOI: 10.1016/j.prostr.2024.01.011

[6] L. Gonçalves, G. Couto, and A. Ramalho, "The influence of layer height in the orthotropic elastic properties of PLA material obtained by additive processes," Procedia Structural Integrity, vol. 53, p.89–96, 2024.

DOI: 10.1016/j.prostr.2024.01.012

[7] L. Barboni, G. R. Gillich, C. P. Chioncel, C. O. Hamat, and I. C. Mituletu, "A Method to Precise Determine the Young's Modulus from Dynamic Measurements," IOP Conf Ser Mater Sci Eng, vol. 416, p.012063, Oct. 2018.

DOI: 10.1088/1757-899X/416/1/012063

[8] F. Antunes, A. Ramalho, J. A. M. Ferreira, C. Capela, and P. Reis, "Determination of Elastic Properties by Resonant Technique: A Sensitivity Analysis," J Test Eval, vol. 36, no. 1, p.89–99, Jan. 2008.

DOI: 10.1520/JTE101041

[9] M. M. Shokrieh and H. Moshrefzadeh-Sani, "On the constant parameters of Halpin-Tsai equation," Polymer (Guildf), vol. 106, p.14–20, Dec. 2016.

DOI: 10.1016/j.polymer.2016.10.049

[10] MSC.Software Corporation, "Patran 2008 Reference Manual Part 4: Functional Assignments," Santa Ana, CA 92707 USA, 2008. [Online]. Available: www.mscsoftware.com

[11] P. D. Stukhlyak et al., "Structural fracture scales in shock-loaded epoxy composites," Physical Mesomechanics, vol. 18, no. 1, p.58–74, Jan. 2015.

DOI: 10.1134/S1029959915010075

[12] "MATWEB." Accessed: Mar. 12, 2024. [Online]. Available: https://www.matweb.com/search/DataSheet.aspx?MatGUID=d9c18047c49147a2a7c0b0bb1743e812&ckck=1

[13] A. Ramalho, M. Ferraz, M. Gaspar, and C. Capela, "Influence of Materials and Their Constitutive Laws on the Stress Fields Produced in the Residual Limb of a Transfemoral Amputation," 2022, p.53–66.

DOI: 10.1007/978-981-16-9632-9_7

[14] J. D. Lorde and R. Morrel, "Elastic Modulus Measurement. A National Measurement Good Practice Guide. National Physical Laboratory," Teddington, Middlesex, UK, 2006.

[15] S. Puchegger, D. Loidl, H. Peterlik, and K. Kromp, "Determination of Elastic Modules in Dependence on Orientation by the Resonant Beam Technique," Materials Science Forum, vol. 514–516, p.815–824, May 2006.

DOI: 10.4028/www.scientific.net/MSF.514-516.815
