Investigation of Electro-Mechanical Properties of SR/CNT/SR Flexible Strain Sensor Composites

Abstract:

In recent years, flexible strain sensors with high sensitivity and a wide sensing range have been developed for biosensors, wearable sensors, electronic skin, and soft robots. In this study, SR/CNT/SR composite-based sensors were fabricated using the sandwich manufacturing method. The sensors were then analyzed for electro-mechanical properties to test their performance. The flexible strain sensor showed a high sensitivity of 76.60 at 0-80% strain range. In addition, the sensor also showed a high linearity of 0.978 in one linear region. The sensor also constantly changes relative resistance at 10 cycles in the 0-40% range. While in the 45-80% strain range, the relative resistance value fluctuates. This is due to the large crack in the sensor when stretched. This sensor also has a fast response time of about 80 ms and a fast recovery of around 95 ms. This flexible strain sensor is also stable for durability testing at 500 loading and release cycles.

• Periodical: Solid State Phenomena (Volume 372)
• Pages: 51-56
• DOI: https://doi.org/10.4028/p-IsM5R3
• Online since: July 2025
• Authors: Muhammad Luthfi Hakim, Muhammad Akhsin Muflikhun, Herianto Herianto*
• Keywords: Durability, Electro-Mechanical, Flexible Strain Sensor, Linearity, Response and Recovery Time, Sensitivity

References

[1] K. Meng et al., "Wearable Pressure Sensors for Pulse Wave Monitoring," Adv. Mater., vol. 34, no. 21, p.2109357, 2022.

DOI: 10.1002/adma.202109357

[2] X. Dang, Y. Fu, and X. Wang, "A temperature and pressure dual-responsive, stretchable, healable, adhesive, and biocompatible carboxymethyl cellulose-based conductive hydrogels for flexible wearable strain sensor," Biosens. Bioelectron., vol. 246, p.115893, 2024.

DOI: 10.1016/j.bios.2023.115893

[3] J. He et al., "Multi-directional strain sensor based on carbon nanotube array for human motion monitoring and gesture recognition," Carbon N. Y., vol. 226, p.119201, 2024.

DOI: 10.1016/j.carbon.2024.119201

[4] L. Li et al., "One-dimensional hierarchically structured strain sensor with high sensitivity, stretchability and durability for physiological monitoring," Mater. Res. Bull., vol. 177, p.112876, 2024.

DOI: 10.1016/j.materresbull.2024.112876

[5] Y. Lin, Q. Yin, H. Jia, Q. Ji, and J. Wang, "Ultrasensitive and highly stretchable bilayer strain sensor based on bandage-assisted woven fabric with reduced graphene oxide and liquid metal," Chem. Eng. J., vol. 487, p.150777, 2024, doi: https://doi.org/10.1016/j.cej. 2024.150777.

DOI: 10.1016/j.cej.2024.150777

[6] G. Li et al., "Wide strain range and high sensitivity sandwich structure CNTs/AgNWs/CNTs/TPU strain sensors for human motion detection," Sensors Actuators A Phys., vol. 366, p.114998, 2024.

DOI: 10.1016/j.sna.2023.114998

[7] A. Huang et al., "Lightweight, porous, stretchable nanocomposite foams with sandwich-like and bimodal cell structure by supercritical fluids-assisted processing for flexible strain sensor," J. Supercrit. Fluids, vol. 204, p.106112, 2024.

DOI: 10.1016/j.supflu.2023.106112

[8] Y. Kim, J. Lee, and S.-K. Kang, "Ultrasensitive crack-based strain sensors: mechanism, performance, and biomedical applications," J. Mech. Sci. Technol., vol. 36, no. 3, p.1059–1077, 2022.

DOI: 10.1007/s12206-022-0246-z

[9] D. Kang et al., "Ultrasensitive mechanical crack-based sensor inspired by the spider sensory system," Nature, vol. 516, no. 7530, p.222–226, 2014.

DOI: 10.1038/nature14002

[10] W. Wang et al., "From network to channel: Crack-based strain sensors with high sensitivity, stretchability, and linearity via strain engineering," Nano Energy, vol. 116, p.108832, 2023.

DOI: 10.1016/j.nanoen.2023.108832

[11] H. Yuan, P. Li, X. Wang, C. Yu, X. Wang, and J. Sun, "Stretchable, ultrasensitive strain sensor with high-linearity by constructing crack-based dual conductive network," Chem. Eng. J., vol. 480, p.148102, 2024.

DOI: 10.1016/j.cej.2023.148102

[12] M. L. Hakim, Herianto, and M. A. Muflikhun, "Next-gen strain sensors: self-healing, ultra-sensitive, lightweight, and durable MWCNT-silicone rubber for advanced human motion tracking," J. Eng. Res., 2024.

DOI: 10.1016/j.jer.2024.10.009

[13] D. Xiang et al., "Bilayer-structured carbon nanotube/ethylene–vinyl acetate flexible strain sensors with enhanced sensing performance prepared by biaxial stretching," Sensors Actuators A Phys., vol. 366, p.114992, 2024.

DOI: 10.1016/j.sna.2023.114992

[14] Y. Lin, S. Liu, S. Chen, Y. Wei, X. Dong, and L. Liu, "A highly stretchable and sensitive strain sensor based on graphene–elastomer composites with a novel double-interconnected network," J. Mater. Chem. C, vol. 4, no. 26, p.6345–6352, 2016.

DOI: 10.1039/C6TC01925K

[15] L. Luo et al., "High sensitivity and wide sensing range graphene flexible strain sensors based on pre-stretching and layer-by-layer self-assembly," Surfaces and Interfaces, vol. 49, p.104385, 2024.

DOI: 10.1016/j.surfin.2024.104385

[16] H. Lin et al., "A flexible PTI-CNT strain sensor with high stretchable and sensitive for human movement and vocal cord vibration monitoring," Polymer (Guildf)., vol. 299, p.126887, 2024.

DOI: 10.1016/j.polymer.2024.126887

[17] J. Gu, D. Kwon, J. Ahn, and I. Park, "Wearable Strain Sensors Using Light Transmittance Change of Carbon Nanotube-Embedded Elastomers with Microcracks," ACS Appl. Mater. Interfaces, vol. 12, no. 9, p.10908–10917, Mar. 2020.

DOI: 10.1021/acsami.9b18069

[18] Y. Yang, C. Luo, J. Jia, Y. Sun, Q. Fu, and C. Pan, "A Wrinkled Ag/CNTs-PDMS Composite Film for a High-Performance Flexible Sensor and Its Applications in Human-Body Single Monitoring," Nanomaterials, vol. 9, no. 6, 2019.

DOI: 10.3390/nano9060850

[19] R. Li et al., "Fe NWs/CNT/PUS composite constructed rigid-flexible coupling 3D porous structure with highly linear response and large strain for strain sensor," Sensors Actuators A Phys., vol. 353, p.114211, 2023.

DOI: 10.1016/j.sna.2023.114211
