Frequency Effect on SEU of D Flip-Flop

Abstract:

At present, the research on the radiation-harden ability is the hot spot in the field of aerospace devices. In the paper, one commercial D flip-flop chain and one radiation-harden D flip-flop chain are chosen to be tested on the five conditions of different work frequency in the range of 100k~100M. The test would help us to study the frequency effect on SEE. The result shows that when the work frequency increases 10³times, the upset threshold of commercial D flip-flop chain is almost unchanged, but the saturation cross section of the single event upset (SEU) increases about 7.13 times. Compared with radiation-harden D flip-flop chain, the reinforced chain has higher upset threshold, lower upset saturation cross section, and the saturation cross section increases about 3.71 times when the work frequency increases 10³ times.

You might also be interested in these eBooks

Mechanical and Aerospace Engineering, ICMAE2011

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 110-116)

Pages:

3132-3137

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.110-116.3132

Citation:

Cite this paper

Online since:

October 2011

Authors:

Pan Dong, Long Fan, Hong Chao Zheng, Suge Yue

Keywords:

D Flip-Flop, Frequency, SEE, Set, SEU

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] K. Joe Hass Jody W. Gambles: Mitigating Single Event UpsetsFrom Combinational Logic, 7th NASA Symposium on VLSI Design (1998).

Google Scholar

[2] M. Shoga, K. Jobe, M. Glasgow etc.: Single Event Upset at Gigahertz Frequencies，IEEE TRANSACTIONS ON NUCLEAR SCIENCE, VOL. 41. 6 (1994).

DOI: 10.1109/23.340572

Google Scholar

[3] M. W. Savage, J. L. Titus,T. L. Turflinger, R. L. Pease, and C. Poivey: A comprehensive Analog Single Event Transient Analysis Methodology, IEEE transactions on nuclear science, vol. 51. 6（2004）.

DOI: 10.1109/tns.2004.839107

Google Scholar

[4] Matthew J. Gadalge, Ronald D. Schrimpf: Single Event Transient Pulse Widths in Digital Microcircuits, IEEE transactions on nuclear science, VOL. 51. 6(2004).

DOI: 10.1109/tns.2004.839174

Google Scholar

[5] P. Eaton, J. Benedetto: Single Event Transient Pulse Width Measurements Using a Variable Temporal Latch Technique, IEEE transactions on nuclear science, VOL. 51. 6( 2004).

DOI: 10.1109/tns.2004.840020

Google Scholar
