Effect of Hydrostatic Pressure and Depth of Fluid on the Vibrating Rectangular Plates Partially in Contact with a Fluid

Abstract:

This study is focused on vibration analysis of a rectangular plate in partial coupled with a vertical bounded fluid. The fluid displacement potential satisfying the fluid boundary conditions is derived and the wet dynamic modal functions of the plate are expanded in terms of the finite Fourier series for a compatibility requirement along the contacting surface between the plate and the fluid. The natural frequencies of the plate coupled with sloshing fluid modes are calculated using Rayleigh–Ritz method based on minimizing the Rayleigh quotient. The proposed analytical method is verified by comparing the presented results with the results obtained by three–dimensional finite element analysis. Finally, the influence of hydrostatic pressure and fluid depth on the natural frequencies are examined and discussed in details.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 927-935
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.927
• Online since: October 2011
• Authors: Korosh Khorshidi
• Keywords: Rectangular Plate, Rigid Tank, Sloshing, Wet Frequancy

References

[1] Fu, Y. and Price, W.G. Interactions between a partially or totally immersed vibrating cantilever plate and the surrounding fluid, J. of Sound and Vibration, 118, p.495–513 (1987).

DOI: 10.1016/0022-460x(87)90366-x

[2] Robinson, N.J. and Palmer, S.C. A modal analysis of a rectangular plate floating on an incompressible fluid, J. of Sound and Vibration, 142, p.435–460 (1990).

DOI: 10.1016/0022-460x(90)90661-i

[3] Kwak, M.K. Hydroelastic vibration of rectangular plates, Transaction of the American Society of Mechanical Engineers, J. of Applied Mechanics, 63, p.110–115 (1996).

DOI: 10.1115/1.2787184

[4] Cheung, Y.K. and Zhou, D. Coupled vibratory characteristics of a rectangular container bottom plate, J. of Fluids and Structures, 14, p.339–357 (2000).

DOI: 10.1006/jfls.1999.0272

[5] Chang, T.P. and Liu, M. –F. on the natural frequency of a rectangular isotropic plate in contact with fluid, J. of Sound and Vibration, 236, p.547–553 (2000).

DOI: 10.1006/jsvi.2000.2955

[6] Jeong, K. -H. and Kim, J. -W., Hydrostatic vibration analysis of two flexible rectangular plates partially coupled with liquid, Nuclear Engineering and Technology, 41(3), pp.335-345, (2009).

DOI: 10.5516/net.2009.41.3.335

[7] Jeong, K. -H., Lee, G. -M., Kim, T. -W., Park, K. -B., Free Vibration of a rectangular plate partially in contact with a liquid at both sides, The Korean Society for Noise and Vibration Engineering, 18(1), pp.123-130, (2008) (In Korean).

DOI: 10.5050/ksnvn.2008.18.1.123

[8] Jeong, K. H., Yoo, G. H. and Lee, S. C. Hydroelastic vibration of two identical rectangular plates, J. of Sound and Vibration, 272, p.539–555 (2003).

DOI: 10.1016/s0022-460x(03)00383-3

[9] Zhou, D. and Liu, W. Hydroelastic vibrations of flexible rectangular tanks partially filled with fluid, Int. J. for Numerical Methods in Engineering, 71, p.149–174 (2007).

DOI: 10.1002/nme.1921
