Moving Path Analysis of a Cannonball Colliding onto Water

Abstract:

When a cannonball collides onto water, it can ricochet several times because normal force is generated larger than the weight. In order to determine the moving path, an analysis is done to calculate the position and velocity of the cannonball and the force acting on the cannonball using a finite element method. It is shown that the cannonball motion depends on the initial conditions such as cannonball shape, firing velocity, and firing angle.

• Periodical: Applied Mechanics and Materials (Volume 120)
• Pages: 414-417
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.120.414
• Online since: October 2011
• Authors: Joon Sik Youn, Young Hun Jung, Han Seok Bang, Hae Suk Lee, Yeon Sik Cho, Woo Chun Choi
• Keywords: Cannonball, Collision, Moving Path, Ricochet, Velocity, Water

References

[1] J. Y. Do, E. C. Ra, E. J. Kim, K. W. Ryu : Motion of stone skipping simulation by physically- based analysis, JCSE, Vol. 33, pp.147-155, (2006)

[2] Information on http://ktx111.blog.me/125405128

[3] P. A. Henne : Applied computational aerodynamics, Panel Methods, pp.4-1~4-67, (1990)

[4] J. L. Hess : Panel Methods in computational fluid dynamics, Fluid Mech., Vol. 22, pp.255-274, (1990)

DOI: 10.1146/annurev.fl.22.010190.001351

[5] A. B. Wardlaw Jr., A. M. Morrison, J. L. Baldwin : Prediction of impact pressures, forces and moments during vertical and oblique water entry, Naval Surface Weapons Center Report, WOL/TR, pp.77-106, (1977)

DOI: 10.21236/ada041852

[6] I. M. Hutchings : The ricochet of spheres and cylinders from the surface of water, (1976)

[7] W. Johnson : The ricochet of spinning and non-spinning spherical projectiles, mainly from water, part Ⅱ, (1997)

DOI: 10.1016/s0734-743x(97)00033-x

[8] J. Y. Kim : WB Explicit STR, TSNE, (2010)
