Static Balance Method for a Special Gyroscope Rotor with a Spherical Cavity

Abstract:

Balance precision of gyroscope rotor influences its performance directly. Aiming at the special gyroscope with a spherical cavity mentioned in this paper, a static balance method is proposed. This method can determine not only radial direction but also axial direction relative position between the mass center of rotor and the centroid of rotor’s outer outline. Combined with outer outline location, which can determine the relative position and direction between the mass center of rotor and the centroid of rotor’s outer outline, the relative position and direction between the centroid of spherical cavity and the centroid of outer outline can be determined, and we will know the position of removal amount.

• Periodical: Applied Mechanics and Materials (Volumes 16-19)
• Pages: 680-682
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.16-19.680
• Online since: October 2009
• Authors: Da Peng Cui, Ying Xue Yao, Dong Li Qin
• Keywords: Gyroscope, Removal Amount, Rotor, Static Balance

References

[1] H.B. Zhang: Key Technologies for $ew 2-DOF Air-floated Spherical Gyroscope (Ph. D Harbin institute of technology 2006).

[2] H.S. Wang, B.L. Li, Q.L. Wang and H. Wang, China Patent CN1955706. (2007).

[3] B.L. Li, H.S. Wang and H. Wang: Submitted to Journal of Engineering Design (2006).

[4] D.Y. Su: Submitted to Journal of Southeast University (1991).

[5] L. Zhang, T. Yang and J.M. Wang: submitted to Journal of Projectiles, Rockets, Missiles and Guidance (2007).

[6] X.Y. Zhu, Y.B. Gu and M. Yan: Submitted to Journal of Chinese Inertial Technology (2001).
