Passively Adaptive Compliant Gripper

Abstract:

Gripping and holding of objects are key tasks for robotic manipulators. The development of universal grippers able to pick up unfamiliar objects of widely varying shapes and surfaces is a very challenging task. Passively compliant underactuated mechanisms are one way to obtain the gripper which could accommodate to any irregular and sensitive grasping objects. The purpose of the underactuation is to use the power of one actuator to drive the open and close motion of the gripper. The underactuation can morph shapes of the gripper to accommodate to different objects. As a result, they require less complex control algorithms. The fully compliant mechanism has multiple degrees of freedom and can be considered as an underactuated mechanism. This paper presents a new design of the adaptive underactuated compliant gripper with distributed compliance and embedded sensors in the gripper structure. The adaptive gripper surfaces will have the sensing capability by these embedded sensors. The gripper will be made of a silicone rubber and conductive silicone rubber will be used for the embedded sensors. The main points of this paper are in explanation of the construction and production of the gripper structure and showing the methodology of a new sensing capability of the gripper.

• Periodical: Applied Mechanics and Materials (Volume 162)
• Pages: 316-325
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.162.316
• Online since: March 2012
• Authors: Dalibor Petkovic, Mirna Issa, Nenad D. Pavlovic, Lena Zentner
• Keywords: Compliant Mechanism, Distributed Compliance, Embedded Sensors, Passively Adaptive Gripper

References

[1] Carrozza M. C, Suppo C, Sebastiani F, Massa B, Vecchi F, Lazzarini R, Cutkosky M. R, Dario P, The SPRING Hand: Development of a Self-Adaptive Prosthesis for Restoring Natural Grasping, Autonomous Robots 16, 2004, 125-141.

DOI: 10.1023/b:auro.0000016863.48502.98

[2] Montambault S, Gosselin C. M, Analysis of Underactuated Mechanical Grippers, Journal of Mechanical Design 123, 2001, 367-345.

DOI: 10.1115/1.1374198

[3] Fukaya N, Toyama S, Asfour T, Dillmann R, Montambault S, Gosselin C. M, Design of the TUAT/Karlsruhe humanoid hand, 2000 IEEE/RSJ International Conference on Intelligent Robots and Systems, 2000, 1754-1759.

DOI: 10.1109/iros.2000.895225

[4] Birglen L, The kinematic preshaping of triggered self-adaptive linkage-driven robotic Fingers, Mechanical Science 2, 2011, 41-49.

DOI: 10.5194/ms-2-41-2011

[5] Daniel A, Barrett H, Vincent D, Mark R. C, Varying spring preloads to select grasp strategies in an adaptive hand, IEEE IROS 2011, San Francisco, Sept. 2011, 1-6.

[6] Ciocarlie M, Allen P, Data-driven optimization for underactuated robotic hands, 2010 IEEE International Conference on Robotics and Automation, 2010, 1292-1299.

DOI: 10.1109/robot.2010.5509793

[7] Lu, K. -J., Kota, S, Parametrization strategy for optimization of shape morphing compliant mechanisms using load path representation, In: Proceedings of DETC'03 ASME 2003 Design Engineering Technical Conferences and Computers and Information in Engineering Conference Chicago, Illinois USA, 2003, 693-702.

DOI: 10.1115/detc2003/dac-48775

[8] Lu, K. -J., Kota, S, An effective method of synthesizing compliant adaptive structures using load path representation, J. of Intelligent Material Syst. And Struct. 16, 2005, 307-317.

DOI: 10.1177/1045389x05050104

[9] Lu, K. -J., Kota, S, Compliant mechanism synthesis for shape-change applications: preliminary results, Smart Struct. And Materials. 4693, 2002, 161-172.

[10] Lu, K. -J., Kota, S, Design of compliant mechanisms for morphing structural shapes, J of Intelligent Material and Struct. 14, 2003, 379-391.

DOI: 10.1177/1045389x03035563

[11] Kota, S., Hetrick, J, Osborn, R., Paul, D., Pendleton, E., Flick, P., Tilmann, C, Design and application of compliant mechanisms for morphing aircraft structures, Smart Struct. And Materials. 5054, 2003, 24-33.

DOI: 10.1117/12.483869

[12] Birglem L, Gosselin C. M, Fuzzy Enhanced Control of an Underactuated Finger Using Tactile and Position Sensors, Proceedings of the 2005 IEEE International Conference on Robotics and Automation, 2005, 2320-2325.

DOI: 10.1109/robot.2005.1570459

[13] Luo M, Lu C, Mei T, Zha S, Intelligent grasping of an underactuated hand for space robots, Proc. of 'The 8th International Symposium on Artifical Intelligence, Robotics and Automation in Space - iSAIRAS, 2005, 1-6.

[14] Petković D, Pavlović N. D, A New Principle of Adaptive Compliant Gripper, Proceedings of the First Workshop on Mechanisms, Transmissions and Applications MeTrApp 2011, Timişoara, Romania, 2011, 145-152.

DOI: 10.1007/978-94-007-2727-4_13

[15] Petković D, Pavlović N. D, Investigation and Adaptive Neuro-Fuzzy Estimation of Mechanical/Electrical Properties of Conductive Silicone Rubber, 34th International Conference on Production Engineering, Nis, Serbia, 2011, 385-388.

[16] Issa M, Petković D, Pavlović N. D, Zentner L, Embedded-sensing elements made of conductive silicone rubber for compliant robotic joint, 56th Internationales Wissenschaftliches Kolloquium TU Ilmenau, (CD-ROM), Ilmenau, 2011, paper id 1231.

DOI: 10.1108/01439911311297748
