Design Process of a Robotized Tele-Echography System

Abstract:

This paper deals with the design process of a particular mechatronic system: a tele-echography robot. First, we describe the principle of robotized tele-echography and the prototypes already designed. Then, after having chosen the design process, we show two medical gestures analysis performed to define the required specifications of a tele-echography robot. Several kinematic synthesis allow demonstrating that the serial spherical wrist is the most adapted structure to this medical application. The kinematic performance of this structure is limited by the singularity position located at the centre of the workspace. An inclined spherical wrist structure is proposed to displace the singularity position in a less used workspace zone that the normal direction to the patients skin. In the dimensional synthesis phase, this structure is optimized. Then, a collaborative design study with designers is presented to improve aesthetic and ergonomic of the robot. This step was very interesting because it brought innovative propositions. Finally, a detailed phase allows defining the PROSIT 1 robot. It was manufactured and will be soon tested in clinical environment.

• Periodical: Applied Mechanics and Materials (Volume 162)
• Pages: 384-393
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.162.384
• Online since: March 2012
• Authors: T. Essomba, L. Nouaille, M.A. Laribi, G. Poisson, S. Zeghloul
• Keywords: Design Process, Mechanical, Medical Gesture Analysis, Tele-Echography Robot

References

[1] A. Gourdon, Ph. Poignet, G. Poisson, P. Vieyres, P. Marché, A new robotic mechanism for medical application, ASME 1999, USA.

DOI: 10.1109/aim.1999.803139

[2] A. Vilchis and al , TER: A System for Robotic Tele-Echography, Lecture Notes in Computer Science, vol. 2208, pp.326-334, Springer Verlag, (2001).

[3] P. Vieyres and al., A tele-operated robotic system for mobile tele-echography: The OTELO project, M-health, Emerging Mobile health Systems book, Springer publisher, ISBN: 0-387-26558-9, Chapter 23, pp.461-474, (2006).

DOI: 10.1007/0-387-26559-7_35

[4] M. Mitsuishi and al, Remote Ultrasound Diagnostic System, Proc. IEEE Int. Conf. Robotics and Automation, pp.1567-1574, Korea, (2001).

[5] K. Masuda and al., Three Dimensional Motion Mechanism of Ultrasound Probe and its Application for Tele-echography System, Proc. of International Conference IROS, pp.1112-1116, USA, (2001).

[6] Information on http: /www. medirob. com.

[7] F. Najafi, N. Sepehri, A novel hand controller for remote ultrasound imaging, Science Direct- Mechatronics, (2008).

DOI: 10.1016/j.mechatronics.2008.05.013

[8] D. Brown, Artificial Intelligent for Engineering Design, Analysis and Manufacturing, Special Issue: Configuration Design, vol. 12(4), pp.301-306, (1998).

[9] N.P. Suh, The principles of design, Oxford University Press, New York, (1990).

[10] D. Scavaretti, Prior formulation of a design problem, for design assistance in preliminary design, Ph.D. dissertation, Ecole Nationale Supérieure d'Arts et Métiers, France, (2004).

[11] G. Pahl, W. Beitz, Engineering Design, The Design Council, London, Springer, (1984).

[12] P. Arbeille, J. Ruiz, P. Herve, M. Chevillot, G. Poisson, F. Perrotin. Fetal tele-echography, using a robotic arm and a satellite link. Ultrasound Obstet Gynecol, vol. 26 (3), pp.221-226, (2005).

DOI: 10.1002/uog.1987

[13] L. Al Bassit, Spherical mechanical structure optimized for a mobile medical tele-echography robot, Ph.D. dissertation, University of Orleans, France, (2005).

[14] M.A. Laribi, T. Essomba, S. Zeghloul, G. Poisson, Optimal Synthesis of a New Spherical Parallel Mechanism for Application to Tele-Echography Chain, ASME 2011 IDETC/CIE, August 29-31, Washington DC, USA.

DOI: 10.1115/detc2011-47184

[15] L. Nouaille, Design process of medical robots. Application to a tele-echography robot, PhD. dissertation, University of Orleans, France, (2009).

[16] N. Smith-Guérin, L. Nouaille, P. Vieyres, G. Poisson, A medical robot kinematic design approach based on knowledge management, Industrial Robot, pp.316-323, (2008).

DOI: 10.1108/01439910810876418

[17] L. Nouaille, N. Smith-Guerin, G. Poisson, Modeling and geometrical validation of a tele-echography robot, Proc. of International Conference IROS, Nice, France, (2008).

DOI: 10.1109/iros.2008.4650901

[18] L. Nouaille, N. Smith-Guérin, G. Poisson, Optimization of a 4 dof tele-echography robot, Proc. of International Conference IROS, Taipei, Taïwan, (2010).

DOI: 10.1109/iros.2010.5649680

[19] S. Zeghloul, B. Blanchard, M. Ayrault. SMAR: A Robot Modeling and Simulation System, Robotica Journal, vol. 15, pp.63-73, February (1997).

DOI: 10.1017/s0263574797000088

[20] T. Essomba, M.A. Laribi, J.P. Gazeau, G. Poisson, S. Zehgloul, Contribution to the design of a robotized tele-ultrasound system, IFToMM ISRM 2011, November 3-5, Shanghaï, China.

[21] G. Poisson, P. Poignet, The design of robots for assistance to medical and surgical gestures. Jounées Nationales de la Recherche en Robotique, JNRR'05, 5-7 october 2005, Guidel, France.
